Assembly
100%

475-2470 FRAME GP-UNDERCARRIAGES/N MG51-UP; GB61-UP

Group No: 475-2470
Part NumberPart NameQty
47878371 SCRAPER2
27161922 SCRAPER2
27161933 SCRAPER2
27161964 PLATE2
27339895 ROLLER GP-TRACK-SINGLE FLANGE (SYSTEMONE)16
28357456 CAP GP-TRACK IDLER (INSIDE, LH, OUTSIDE, RH)2
28357497 CAP GP-TRACK IDLER (INSIDE, RH, OUTSIDE, LH)2
33930938 CAP GP-TRACK IDLER (INSIDE, RH, OUTSIDE, LH)2
33930949 CAP GP-TRACK IDLER (INSIDE, LH, OUTSIDE, RH)2
351511410 FRAME GP-TRACK ROLLER (HEAVY-DUTY, SYSTEMONE)1
353218611 PLATE-WEAR (FRONT)4
353218712 PLATE-WEAR (REAR)4
478783413 SCRAPER2
478783814 SCRAPER2
198477815 WASHER-HARD (13.5X30X12-MM THK)32
456990416 IDLER GP-TRACK (SYSTEMONE)(REAR, LH, RH)2
8T419217 BOLT (M12X1.75X25-MM)24
8T419418 BOLT (M12X1.75X50-MM)24
8T422319 WASHER-HARD (13.5X25.5X3-MM THK)24
8T491020 BOLT (M12X1.75X60-MM)8
323116821 IDLER GP-TRACK (SYSTEMONE)(FRONT, LH, RH)2
