System And Components
422-7077 HEATER GP-CABS/N MG51-UP; GB61-UP
Group No: 422-7077
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 3 | |
| 7T8894 | 2 GROMMET | 2 | |
| 9X2185 | 3 SCREW (8-15X0.44-IN) | 4 | |
| 1772215 | 4 STRAP-DUAL CLAMP | 2 | |
| 3949709 | 5 ACTUATOR & VALVE GP-HTR CONT (WATER) | 1 | |
| 3445675 | 6 NUT (M10X1.5-THD) | 2 | |
| 4P7581 | 7 CLIP (LADDER) | 1 | |
| 6D1641 | 8 CLIP (LOOP) | 1 | |
| 8T4121 | 9 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4138 | 10 BOLT (M6X1X20-MM) | 1 | |
| 9X2038 | 11 WASHER (7X19X2-MM THK) | 1 | |
| 9X2488 | 12 CLAMP-HOSE | 4 | |
| 9X8250 | 13 CLIP (LOOP) | 3 | |
| 5P0767 | 14 HOSE (54-CM) | ||
| 5P0767 | 14A HOSE (62-CM) | ||
| 5P0767 | 14B HOSE (131-CM) | ||
| 8T4137 | 15 BOLT (M10X1.5X20-MM) | 1 |
