System And Components
355-1629 PAN GP-OILS/N K3B692-UP
Group No: 355-1629
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E7427 | 1 ADAPTER | 1 | |
| 9X6451 | 2 PLUG-DRAIN (MAGNETIC) | 1 | |
| 9M1974 | 3 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 2173673 | 4 SEAL-ISOLATION | 1 | |
| 3010113 | 5 PAN-OIL | 1 | |
| 3960393 | 6 PLUG AS | 1 | |
| 3603677 | PLUG (7/16-20-THD) | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 3367231 | 7 BELL AS-SUCTION | 1 | |
| 2101743 | ELBOW | 1 | |
| 0619458 | 8 SEAL-O-RING | 2 | |
| 2173674 | 9 FASTENER AS | 14 | |
| 2873049 | 10 STUD (M10X1.5X50-MM) | 5 | |
| 3893728 | 11 PLUG AS | 2 | |
| 3603684 | PLUG | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 3510283 | 12 VALVE AS-SHUTOFF | 1 | |
| 6V7238 | VALVE-SHUTOFF | 1 | |
| 2385080 | SEAL-O-RING | 1 | |
| 3E8016 | 13 BOLT-SELF-LOCKING (M8X1.25X25-MM) | 2 | |
| 5P8211 | 14 SEAL-O-RING | 1 | |
| 5P8245 | 15 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 6A5591 | 16 BOLT (M12X1.75X25-MM) | 2 | |
| 6N8863 | 17 WASHER (10.2X32X2.5-MM THK) | 14 | |
| 6V4249 | 18 BOLT (M10X1.5X50-MM) | 9 |
