449-0547 ENCLOSURE GP-GENERATORS/N NGP1-UP

Group No: 449-0547
Part NumberPart NameQty
4P19911 BUTTON12
13499252 HOLDER4
14269503 HINGE AS8
14281944 RIVET68
14471835 RING-RETAINING118
25148896 WASHER-HARD (7.2X14.5X2-MM THK)27
30826747 PAWL4
35229798 LATCH AS4
5C2890NUT (M6X1-THD)4
1H3244LOCKWASHER4
1608499NUT (M12X1.5-THD)2
3260612WASHER-TAB2
36600839 BRACKET AS4
422605910 PANEL GP-ENCLOSURE1
7X772911 WASHER (11X25X3-MM THK)5
449054812 INSULATION GP-HEAT1
449069213 ENCLOSURE GP-GENSET1
099641814 NUT (M6X1-THD)24
142489915 LOCKWASHER44
142490116 SCREW (M10X1.5X20-MM)52
175714117 NUT-HEX FLANGE (M10X1.5-THD)13
235445118 BOLT-FLANGE HEAD (M6X1X16-MM)55
338366919 BOLT-FLANGE HEAD (M10X1.5X30-MM)69
343407220 BOLT-FLANGE HEAD (M6X1X25-MM)12
6V774321 LOCKNUT (M6X1-THD)12
422606222 WIRE AS4
460904123 DOOR GP-ACCESS1
1428194RIVET21
1447183RING-RETAINING3
4609042DOOR AS1
1428194RIVET4
1428212BRACKET2
4609043DUCT AS1
1428194RIVET10
