280-7691 LINES GP-LUBRICATION -STICKS/N F2W1-UP

Group No: 280-7691
Part NumberPart NameQty
11776341 FITTING-STRAIGHT15
11776352 ELBOW5
11776373 CLAMP10
12999994 CLAMP4
22677875 ADAPTER1
24287136 CONNECTOR2
25426587 LINES GP-LUBRICATION (STICK)1
26815978 CONNECTOR AS4
2681630CONNECTOR1
2681631NUT-COMPRESSION2
2681632SLEEVE2
26816349 ELBOW2
268163710 CONNECTOR AS2
2681631NUT-COMPRESSION1
2681632SLEEVE1
2681633CONNECTOR1
475730511 COVER2
475730612 COVER1
275297613 COVER2
280243514 HOSE AS1
5I4200GUARD (90-CM)
295766515 TUBE1
295766616 TUBE1
296395617 TUBE1
296395718 TUBE1
296489519 CONNECTOR2
147666320 CLAMP5
274835321 BOLT-SOCKET HEAD (M5X0.8X30-MM)2
295415522 BOLT-SOCKET HEAD (M5X0.8X35-MM)1
5C726123 NUT (M8X1.25-THD)2
300373824 BOLT-HEAD (M5X0.8X8-MM)19
8T418925 BOLT (M8X1.25X20-MM)2
8T691226 BOLT (M8X1.25X50-MM)2
7K118127 STRAP-CABLE24
280243328 HOSE AS2
5I4200GUARD (170-CM)
280243429 HOSE AS2
5I4200GUARD (140-CM)
