System And Components
452-6385 CIRCUIT BREAKER GPS/N LX91-UP
Group No: 452-6385
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1434456 | 1 INSULATOR | 2 | |
| 2592211 | 2 CIRCUIT BREAKER AS (630-AMPERE) | 1 | |
| 3478370 | KIT-FASTENER | 1 | |
| 3478382 | KIT-FASTENER | 1 | |
| 2621370 | 3 CONTACT AS-ELECTRICAL | 1 | |
| 3280649 | 4 TERMINAL | 1 | |
| 3352904 | 5 COVER AS-TERMINAL | 1 | |
| 3478376 | 6 MOTOR (24-VOLT) | 1 | |
| 3478381 | 7 TRIP-UNDERVOLTAGE | 1 | |
| 4517759 | 8 BRACKET AS | 1 | |
| 2035398 | INSERT-THREADED (M5X0.8-THD) | 6 | |
| 4526508 | 9 TERMINAL | 6 | |
| 2606672 | 10 BOLT (M8X1.25X20-MM) | 2 | |
| 8T4199 | 11 BOLT (M8X1.25X12-MM) | 2 | |
| 4D1326 | 12 LOCKWASHER | 16 | |
| 7H3937 | 13 LOCKWASHER | 4 | |
| 8T4121 | 14 WASHER-HARD (11X21X2.5-MM THK) | 16 | |
| 8T4133 | 15 NUT (M10X1.5-THD) | 8 | |
| 8T4195 | 16 BOLT (M10X1.5X30-MM) | 8 | |
| 8T4224 | 17 WASHER-HARD (8.8X16X2-MM THK) | 4 |
