System And Components
548-1655 PANEL GP-ELECTRONICS/N LX91-UP
Group No: 548-1655
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1694481 | 1 HINGE AS | 2 | |
| 2069512 | 2 CONTACT | 1 | |
| 2145791 | 3 SWITCH AS-ROTARY (REMOTE START) | 1 | |
| 2266446 | 4 SWITCH AS-PUSH BUTTON (STOP) | 1 | |
| 2615503 | COLLAR | 1 | |
| 2286935 | 5 BLOCK-CONTACT | 1 | |
| 2661570 | 6 LOCK | 2 | |
| 2677279 | 7 GROMMET | 2 | |
| 2677280 | 8 GROMMET | 1 | |
| 3504303 | 9 GROMMET | 7 | |
| 3914275 | 10 FILM-IDENTIFICATION (CONTROL PANEL) | 1 | |
| 4930334 | 11 PANEL AS | 1 | |
| 3E4304 | INSERT-THREADED (M6X1-THD) | 28 | |
| 1428194 | RIVET | 4 | |
| 2035398 | INSERT-THREADED (M5X0.8-THD) | 4 | |
| 2354451 | BOLT-FLANGE HEAD (M6X1X16-MM) | 4 | |
| 5208710 | 12 CONTROL GP-ELECTRONIC | 1 | |
| 5481656 | 13 PANEL AS | 1 | |
| 2354451 | 14 BOLT-FLANGE HEAD (M6X1X16-MM) | 13 | |
| 2078643 | 15 DUCT-WIRE (850-MM) | ||
| 2078643 | 15A DUCT-WIRE (150-MM) | ||
| 2078643 | 15B DUCT-WIRE (650-MM) | ||
| 5P5637 | 16 SEAL (0.48-M) | ||
| 5P5637 | 16A SEAL (1.28-M) |
