System And Components
482-3759 ENCLOSURE GP-GENSETS/N LN91-UP
Group No: 482-3759
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P1991 | 1 BUTTON | 10 | |
| 8C4413 | 2 BALL JOINT | 5 | |
| 1424899 | 3 LOCKWASHER | 40 | |
| 1424901 | 4 SCREW (M10X1.5X20-MM) | 102 | |
| 1426950 | 5 HINGE AS | 10 | |
| 1428194 | 6 RIVET | 28 | |
| 1447183 | 7 RING-RETAINING | 32 | |
| 2130985 | 8 GROMMET | 6 | |
| 2143966 | 9 NUT (M6X1-THD) | 20 | |
| 2197350 | 10 STAY | 5 | |
| 2324944 | 11 GROMMET | 3 | |
| 2354451 | 12 BOLT-FLANGE HEAD (M6X1X16-MM) | 20 | |
| 3292431 | 13 POST-CORNER | 4 | |
| 3319490 | 14 WINDOW | 1 | |
| 3319491 | 15 HANDLE | 2 | |
| 3465504 | 16 CLIP | 48 | |
| 3474025 | 17 HATCH | 1 | |
| 3554785 | 18 RETAINER | 6 | |
| 3620466 | 19 PLUG | 5 | |
| 3660081 | 20 LATCH AS | 5 | |
| 5C2890 | NUT (M6X1-THD) | 4 | |
| 1H3244 | LOCKWASHER | 4 | |
| 8T4244 | NUT (M12X1.75-THD) | 2 | |
| 3260612 | WASHER-TAB | 2 | |
| 3660082 | 21 PAWL | 5 | |
| 3660083 | 22 BRACKET AS | 5 | |
| 3660084 | 23 POST-SIDE | 4 | |
| 3890802 | 24 SILENCER | 1 | |
| 4179229 | 25 CAP-RAIN | 1 | |
| 4823760 | 26 ENCLOSURE GP-GENSET | 1 | |
| 4823763 | 27 INSULATION GP-HEAT | 1 | |
| 3383669 | 28 BOLT-FLANGE HEAD (M10X1.5X30-MM) | 78 | |
| 5C7261 | 29 NUT (M8X1.25-THD) | 5 | |
| 5P4116 | 30 WASHER-HARD (8.8X20.5X2-MM THK) | 5 | |
| 2375071 | 31 SEAL (13-DM) | ||
| 2375072 | 32 SEAL (13-DM) | ||
| 3543882 | 33 SEAL (15-DM EACH) | ||
| 1978039 | 34 SEAL (43.7-DM EACH) | ||
| 1978039 | 34A SEAL (42.2-DM) | ||
| 3517199 | 35 SEAL-FOAM (2.2-DM EACH) | ||
| 3517199 | 35A SEAL-FOAM (15-DM) | ||
| 3517199 | 35B SEAL-FOAM (2.3-DM EACH) | ||
| 3517199 | 35C SEAL-FOAM (4.4-DM EACH) | ||
| 3517199 | 35D SEAL-FOAM (0.5-DM EACH) | ||
| 3517199 | 35E SEAL-FOAM (45-DM EACH) | ||
| 3517199 | 35F SEAL-FOAM (1.8-DM EACH) | ||
| 3517199 | 35G SEAL-FOAM (3.7-DM EACH) | ||
| 3517199 | 35H SEAL-FOAM (13.7-DM EACH) | ||
| 3517199 | 35I SEAL-FOAM (13.5-DM) | ||
| 3517199 | 35J SEAL-FOAM (41.8-DM EACH) |
