System And Components
254-2633 LINES GP-STEERINGS/N EN21-UP
Group No: 254-2633
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1335813 | 1 BAND-MARKER (GRAY, P) | 1 | |
| 1873774 | 2 PUMP GP-METERING (HMU) | 1 | |
| 1881814 | 3 VALVE GP-PRIORITY (MAIN)(STEERING) | 1 | |
| 1457118 | 4 HOSE AS | 1 | |
| 1488326 | 5 CONNECTOR AS | 2 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9872 | CONNECTOR | 1 | |
| 1488340 | 6 CONNECTOR AS | 4 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 1488364 | 7 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8625 | ELBOW | 1 | |
| 1908553 | 8 HOSE AS | 1 | |
| 1908557 | 9 HOSE AS | 1 | |
| 1908558 | 10 HOSE AS | 1 | |
| 1908560 | 11 HOSE AS | 1 | |
| 4I9521 | 12 BAND-MARKER (RED, L1) | 1 | |
| 4I9522 | 13 BAND-MARKER (YELLOW, L2) | 1 | |
| 4I9523 | 14 BAND-MARKER (BLUE, L3) | 1 | |
| 4I9525 | 15 BAND-MARKER (ORANGE, R1) | 1 | |
| 4I9527 | 16 BAND-MARKER (GREEN, R3) | 1 | |
| 4M6921 | 17 WASHER-SPRING | 4 | |
| 5C7261 | 18 NUT (M8X1.25-THD) | 2 | |
| 8T4137 | 19 BOLT (M10X1.5X20-MM) | 4 | |
| 8T4224 | 20 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T6912 | 21 BOLT (M8X1.25X50-MM) | 1 | |
| 8T7329 | 22 BOLT (M8X1.25X55-MM) | 1 | |
| 2010048 | KIT-SEAL (STEERING PUMP) | 1 |
