System And Components
276-8020 PUMP GP-FUEL PRM & SEC FILTERS/N FTH1-UP; LXL1-UP
Group No: 276-8020
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P0436 | 1 GASKET (FUEL PRIMING PUMP) | 1 | |
| 1375541 | 2 PUMP GP-FUEL PRIMING | 1 | |
| 3885388 | 3 BASE GP-FUEL FILTER | 1 | |
| 2345013 | 4 SENSOR GP-TEMPERATURE (FUEL) | 1 | |
| 2764754 | 5 HARNESS AS-PUMP (FUEL) | 1 | |
| 8T8737 | PLUG-SEAL | 3 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 5 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 5 | |
| 1945226 | TERMINAL AS (16-GA) | 5 | |
| 1945227 | TERMINAL AS (14-GA) | 5 | |
| 2304011 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 4550704 | SEAL-CONNECTOR | 1 | |
| 2312300 | RECEPTACLE AS-CONNECTOR (8-PIN) | 1 | |
| 2370227 | PLUG AS-CONNECTOR (3-PIN) | 1 | |
| 4550705 | SEAL-CONNECTOR | 1 | |
| 2746719 | 6 SENSOR GP-PRESSURE (3-PIN)(FUEL) | 1 | |
| 1B7182 | 7 BOLT (5/16-18X1.25-IN) | 1 | |
| 1R0749 | 8 FILTER-FUEL (ADVANCED EFFICIENCY)(SECONDARY) | 1 | |
| 5P0537 | 9 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 3295451 | 10 ADAPTER AS | 1 | |
| 9X0261 | ADAPTER | 1 | |
| 2147566 | SEAL-O-RING | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 7B2742 | 11 BOLT (1/4-20X1.25-IN) | 1 | |
| 9M1974 | 12 WASHER-HARD (8.8X16X2-MM THK) | 1 |
