System And Components
342-9243 WEIGHT GP-ECCENTRICS/N DJM128-172
Group No: 342-9243
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4B4158 | 1 SCREW-DRIVE (NO 4X0.25-IN) | 2 | |
| 5E8394 | 2 SHAFT | 1 | |
| 9Y9236 | 3 GAUGE-SIGHT (ECCENTRIC WEIGHT HOUSING) | 1 | |
| 0813292 | 4 PIN | 2 | |
| 0813814 | 5 SEAL-O-RING | 1 | |
| 0813853 | 6 SEAL-O-RING | 1 | |
| 1069045 | 7 PLATE-FILLER | 2 | |
| 1467512 | 8 PLATE-IDENTIFICATION (ECCENTRIC WEIGHT) | 1 | |
| 1654929 | 9 PLUG AS-MAGNETIC | 1 | |
| 5P4484 | PLUG-MAGNETIC (ECCENTRIC WEIGHT HOUSING) | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1862928 | 10 BUSHING | 1 | |
| 1889926 | 11 SEAL | 2 | |
| 1889927 | 12 SLEEVE | 2 | |
| 1893268 | 13 RING | 2 | |
| 1974732 | 14 SHAFT GP-ECCENTRIC WEIGHT | 1 | |
| 1974733 | 15 COVER | 2 | |
| 1974745 | 16 BUSHING | 2 | |
| 1981437 | 17 KEY-DRIVER | 1 | |
| 2194691 | 18 SPRING | 1 | |
| 2222816 | 19 BLOCK-THRUST | 1 | |
| 2283589 | 20 PIN-SPRING | 1 | |
| 2305462 | 21 SHAFT | 1 | |
| 2416172 | 22 ELBOW AS | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1730064 | ELBOW | 1 | |
| 2694699 | 23 SHAFT | 1 | |
| 2712067 | 24 HOUSING | 1 | |
| 2712068 | 25 HOUSING | 1 | |
| 2874136 | 26 BEARING | 2 | |
| 0813364 | 27 SEAL-O-RING | 2 | |
| 5P8245 | 28 WASHER-HARD (13.5X25.5X3-MM THK) | 7 | |
| 6V2317 | 29 BOLT (M8X1.25X30-MM) | 14 | |
| 7M8485 | 30 SEAL-O-RING | 1 | |
| 7X2537 | 31 BOLT (M8X1.25X35-MM) | 6 | |
| 8T4224 | 32 WASHER-HARD (8.8X16X2-MM THK) | 20 | |
| 8T4779 | 33 BOLT (M16X2X35-MM) | 3 | |
| 9X2145 | 34 BOLT (M12X1.75-THD) | 7 | |
| 9X8257 | 35 WASHER (17.5X30X3.5-MM THK) | 3 |
