374-7677 CONSOLE GP-INSTRUMENT -RHS/N JFC1-122

Group No: 374-7677

Part Number	Part Name	Qty
7K1181	1 STRAP-CABLE	2
3679470	2 SWITCH AS-PUSH BUTTON (EMERGENCY STOP)	1
1028804	KIT-RECEPTACLE (4-PIN)	1
9X3401	PIN-CONNECTOR (16-GA TO 18-GA)	4
3684778	3 FILM-WARNING (EMERGENCY STOP)	1
3747679	4 CONSOLE	1
3747692	5 MODULE GP-KEYPAD	1
8F1326	WASHER (4.2X9.5X0.8-MM THK)	4
8T2659	LOCKNUT (M4X0.7-THD)	4
3950256	6 SWITCH AS-HORN (PUSH BUTTON)	1
1028802	KIT-RECEPTACLE (2-PIN)	1
9X3401	PIN-CONNECTOR (16-GA TO 18-GA)	2
1261767	PIN-CONNECTOR (14-GA TO 16-GA)	2
4202583	7 FILM-INSTRUCTION (PROPEL CONTROL)	1
4202584	8 FILM-INSTRUCTION (CONVEYOR CONTROL)	1
4700206	9 PLATE	2
4725507	10 CONTROL GP-PROPEL (LEVER CONTROLS)	1
1603518	KIT-RECEPTACLE (8-PIN)	1
9X3401	PIN-CONNECTOR (16-GA TO 18-GA)	8
1261767	PIN-CONNECTOR (14-GA TO 16-GA)	8
4725508	11 CONTROL GP-CONVEYOR (LH)	1
1603518	KIT-RECEPTACLE (8-PIN)	1
9X3401	PIN-CONNECTOR (16-GA TO 18-GA)	8
1261767	PIN-CONNECTOR (14-GA TO 16-GA)	8
4739742	12 CONSOLE	1
4958040	13 MODULE GP-KEYPAD	1
4910878	13A SWITCH AS-ROCKER (FRONT RIGHT)	1
4910878	13B SWITCH AS-ROCKER (FRONT LEFT)	1
4910878	13C SWITCH AS-ROCKER (REAR STEERING CONTROL)	1
9X3402	SOCKET-CONNECTOR (16-GA TO 18-GA)	4
1261768	SOCKET-CONNECTOR (14-GA TO 16-GA)	4
1762947	KIT-CONNECTING PLUG (4-PIN)	1
4879663	14 HARNESS AS-PANEL	1
0338248	15 CLIP (LOOP)	1
1185125	16 CLIP (LOOP)	1
1470385	17 CLIP	1
5C2874	19 NUT (M5X0.8-THD)	9
6D5729	20 GROMMET	1
8C8580	21 BOLT-SOCKET HEAD (M5X0.8X16-MM)	8
8M2771	22 CLIP	1
8T0328	23 WASHER-HARD (5.5X10X1-MM THK)	7
8T4205	24 WASHER-HARD (7.2X14.5X2-MM THK)	2
9X2044	25 SCREW-TRUSS HEAD (M6X1X16-MM)	8
4P7581	26 CLIP (LADDER)	1
2663316	27 BOLT-FLANGE HEAD (M10X1.5X25-MM)	1
