System And Components
396-7245 BAR GP-SPRAYS/N JCF1-UP
Group No: 396-7245
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4782768 | 1 FLANGE (MANIFOLD) | 1 | |
| 4782775 | 2 CLAMP AS | 1 | |
| 4782770 | 3 ADAPTER-ELBOW | 1 | |
| 4782771 | 4 KIT-ADAPTER | 1 | |
| 8T9521 | SEAL-O-RING | 4 | |
| 0965486 | SCREW-MACHINE (M6X1X25-MM) | 4 | |
| 3445673 | NUT (M6X1-THD) | 4 | |
| 4782772 | 5 KIT-ADAPTER | 2 | |
| 8T9521 | SEAL-O-RING | 2 | |
| 0965486 | SCREW-MACHINE (M6X1X25-MM) | 2 | |
| 3445673 | NUT (M6X1-THD) | 2 | |
| 4782769 | 6 CAMLOCK | 1 | |
| 4782776 | 7 KIT-CLAMP | 2 | |
| 4B2047 | NUT (10-24-THD) | 2 | |
| 5P8066 | SEAL-O-RING | 1 | |
| 2020309 | SCREW-PAN HEAD | 2 | |
| 4782766 | 8 CLAMP AS | 20 | |
| 4782767 | 9 CAP | 20 | |
| 4782773 | 10 GASKET | 1 |
