System And Components
464-2494 DOOR GP-ACCESS -LHS/N LB81-299
Group No: 464-2494
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4136 | 1 BOLT (M10X1.5X25-MM) | 26 | |
| 8T4186 | 2 BOLT (M10X1.5X40-MM) | 2 | |
| 8T4195 | 3 BOLT (M10X1.5X30-MM) | 5 | |
| 8T4189 | 4 BOLT (M8X1.25X20-MM) | 22 | |
| 3T0852 | 5 LOCKNUT (M8X1.25-THD) | 3 | |
| 8T4908 | 6 BOLT (M8X1.25X25-MM) | 25 | |
| 3B4617 | 7 PIN-COTTER | 2 | |
| 4I3255 | 8 NUT-PUSH ON | 4 | |
| 5C2874 | 9 NUT (M5X0.8-THD) | 6 | |
| 5P4116 | 10 WASHER-HARD (8.8X20.5X2-MM THK) | 58 | |
| 6V7357 | 11 BOLT (M6X1X25-MM) | 2 | |
| 8T0328 | 12 WASHER-HARD (5.5X10X1-MM THK) | 6 | |
| 8T4121 | 13 WASHER-HARD (11X21X2.5-MM THK) | 28 | |
| 8T4137 | 14 BOLT (M10X1.5X20-MM) | 24 | |
| 8T4223 | 15 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4224 | 16 WASHER-HARD (8.8X16X2-MM THK) | 10 | |
| 4642543 | 17 BRACKET | 1 | |
| 8T5447 | 18 RING-RETAINING | 3 | |
| 8T7547 | 19 BOLT (M8X1.25X30-MM) | 4 | |
| 9X8256 | 20 WASHER (6.6X12X2-MM THK) | 6 | |
| 1087756 | 21 ROD | 2 | |
| 1111777 | 22 BUMPER-RUBBER | 11 | |
| 1293178 | 23 LOCKNUT (M6X1-THD) | 2 | |
| 2225151 | 24 PAWL | 2 | |
| 2567669 | 25 PLATE | 17 | |
| 2567670 | 26 SPACER (SPECIAL) | 1 | |
| 2597000 | 27 SPRING-GAS | 1 | |
| 2869963 | 28 LATCH AS | 2 | |
| 2895247 | 29 CAM | 1 | |
| 2895248 | 30 CAM | 1 | |
| 3053156 | 31 PAWL | 1 | |
| 3053169 | 32 PAWL | 1 | |
| 3260610 | 33 LATCH AS | 2 | |
| 1H3244 | LOCKWASHER | 4 | |
| 0966331 | NUT (M12X1.75-THD) | 2 | |
| 3260612 | WASHER-TAB | 2 | |
| 3445673 | NUT (M6X1-THD) | 4 | |
| 2564000 | 34 SPACER (SPECIAL) | 2 | |
| 3336459 | 35 BRACKET | 2 | |
| 3445674 | 36 NUT (M8X1.25-THD) | 2 | |
| 3445675 | 37 NUT (M10X1.5-THD) | 1 | |
| 3879574 | 38 DOOR AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 4 | |
| 3879576 | 39 DOOR (FUEL FILL) | 1 | |
| 3896955 | 40 LOCK AS | 2 | |
| 3899524 | 41 COVER | 1 | |
| 3972993 | 42 COVER | 1 | |
| 3973626 | 43 COVER | 1 | |
| 3974849 | 44 SPRING AS-GAS (DOOR) | 2 | |
| 3974851 | 45 PLATE | 1 | |
| 4642498 | 46 BOX AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 4 | |
| 7T1099 | LINK | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 10 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 3 | |
| 8T8874 | NUT-WELD (M5X0.8-THD) | 2 | |
| 1305300 | CLIP | 1 | |
| 3986427 | 47 BRACKET | 1 | |
| 4642511 | 48 PANEL AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 4642514 | 49 DOOR AS | 1 | |
| 1533723 | HINGE AS | 3 | |
| 8T5447 | RING-RETAINING | 1 | |
| 4642517 | 50 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 1305300 | CLIP | 1 | |
| 3154131 | NUT-WELD (M10X1.5-THD) | 2 | |
| 4642518 | 51 BOX AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 4 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 4 | |
| 2377506 | HOOK | 1 | |
| 4642525 | 52 DOOR (LH) | 1 | |
| 4642529 | 53 DOOR AS | 1 | |
| 4642531 | 54 COVER AS | 1 | |
| 7T1099 | LINK | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 9 | |
| 3154131 | NUT-WELD (M10X1.5-THD) | 2 | |
| 4642541 | 55 DOOR (FRONT) | 1 | |
| 4642542 | 56 DOOR (REAR LOWER, LH) | 1 | |
| 4649653 | 57 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 4 | |
| 4862847 | 58 STORAGE AS | 1 | |
| 7T1099 | LINK | 6 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 22 | |
| 1305300 | CLIP | 2 | |
| 4870658 | 59 PANEL | 1 | |
| 5529761 | 60 GUARD AS-BELT | 1 | |
| 4898228 | 61 HINGE AS | 13 | |
| 1617632 | 62 BOLT-SELF-LOCKING (M10X1.5X40-MM) | 4 | |
| 6R7943 | 63 SCREW (M5X0.8X15-MM) | 6 | |
| 7X7729 | 64 WASHER (11X25X3-MM THK) | 34 | |
| 3426093 | 65 STUD-BALL | 3 | |
| 8T4192 | 66 BOLT (M12X1.75X25-MM) | 2 | |
| 8T4200 | 67 BOLT (M8X1.25X16-MM) | 12 | |
| 1268472 | 68 SEAL (85-CM) | ||
| 1455664 | 69 SEAL (92-CM) |
