System And Components
593-2674 DOOR GP-ACCESS -LHS/N LB8300-UP
Group No: 593-2674
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4642543 | 1 BRACKET | 1 | |
| 4898228 | 2 HINGE AS | 13 | |
| 8T4186 | 3 BOLT (M10X1.5X40-MM) | 2 | |
| 8T4189 | 4 BOLT (M8X1.25X20-MM) | 22 | |
| 8T4192 | 5 BOLT (M12X1.75X25-MM) | 2 | |
| 8T4200 | 6 BOLT (M8X1.25X16-MM) | 12 | |
| 1087756 | 7 ROD | 2 | |
| 1111777 | 8 BUMPER-RUBBER | 11 | |
| 1293178 | 9 LOCKNUT (M6X1-THD) | 2 | |
| 1617632 | 10 BOLT-SELF-LOCKING (M10X1.5X40-MM) | 4 | |
| 2225151 | 11 PAWL | 2 | |
| 2564000 | 12 SPACER | 2 | |
| 2567669 | 13 PLATE | 17 | |
| 2567670 | 14 SPACER | 1 | |
| 2597000 | 15 SPRING-GAS | 1 | |
| 2869963 | 16 LATCH AS | 2 | |
| 2895247 | 17 CAM | 1 | |
| 2895248 | 18 CAM | 1 | |
| 3053156 | 19 PAWL | 1 | |
| 3053169 | 20 PAWL | 1 | |
| 3260610 | 21 LATCH AS | 2 | |
| 1H3244 | LOCKWASHER | 4 | |
| 0966331 | NUT (M12X1.75-THD) | 2 | |
| 3260612 | WASHER-TAB | 2 | |
| 3445673 | NUT (M6X1-THD) | 4 | |
| 3336459 | 22 BRACKET | 2 | |
| 3426093 | 23 STUD-BALL | 3 | |
| 3445674 | 24 NUT (M8X1.25-THD) | 2 | |
| 3445675 | 25 NUT (M10X1.5-THD) | 1 | |
| 3879574 | 26 DOOR AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 4 | |
| 3879576 | 27 DOOR (FUEL FILL) | 1 | |
| 3896955 | 28 LOCK AS | 2 | |
| 3972993 | 29 COVER | 1 | |
| 3973626 | 30 COVER | 1 | |
| 3974849 | 31 SPRING AS-GAS | 2 | |
| 3974851 | 32 PLATE | 1 | |
| 3986427 | 33 BRACKET | 1 | |
| 3B4617 | 34 PIN-COTTER | 2 | |
| 3T0852 | 35 LOCKNUT (M8X1.25-THD) | 3 | |
| 4642511 | 36 PANEL AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 4642514 | 37 DOOR AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 1 | |
| 1533723 | HINGE AS | 3 | |
| 8T5447 | RING-RETAINING | 1 | |
| 4642517 | 38 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 1305300 | CLIP | 1 | |
| 3154131 | NUT-WELD (M10X1.5-THD) | 2 | |
| 4642525 | 39 DOOR | 1 | |
| 4642529 | 40 DOOR AS | 1 | |
| 4642531 | 41 COVER AS | 1 | |
| 7T1099 | LINK | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 9 | |
| 3154131 | NUT-WELD (M10X1.5-THD) | 2 | |
| 4642541 | 42 DOOR | 1 | |
| 4642542 | 43 DOOR | 1 | |
| 4649653 | 44 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 4 | |
| 4862847 | 45 STORAGE AS | 1 | |
| 7T1099 | LINK | 6 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 22 | |
| 1305300 | CLIP | 2 | |
| 4870658 | 46 PANEL | 1 | |
| 4I3255 | 47 NUT-PUSH ON | 4 | |
| 5529761 | 48 GUARD AS-BELT | 1 | |
| 5932650 | 49 BOX AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 4 | |
| 7T1099 | LINK | 2 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 10 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 3 | |
| 8T8874 | NUT-WELD (M5X0.8-THD) | 2 | |
| 1305300 | CLIP | 1 | |
| 2377506 | HOOK | 1 | |
| 5932660 | 50 BOX AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 4 | |
| 7T1099 | LINK | 2 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 4 | |
| 2377506 | HOOK | 1 | |
| 3615420 | CLIP | 2 | |
| 5932667 | 51 COVER AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 9X2032 | NUT-WELD (M4X0.7-THD) | 2 | |
| 5C2874 | 52 NUT (M5X0.8-THD) | 6 | |
| 5P4116 | 53 WASHER-HARD (8.8X20.5X2-MM THK) | 58 | |
| 6R7943 | 54 SCREW (M5X0.8X15-MM) | 6 | |
| 6V7357 | 55 BOLT (M6X1X25-MM) | 2 | |
| 7X7729 | 56 WASHER (11X25X3-MM THK) | 34 | |
| 8T0328 | 57 WASHER-HARD (5.5X10X1-MM THK) | 6 | |
| 8T4121 | 58 WASHER-HARD (11X21X2.5-MM THK) | 28 | |
| 8T4136 | 59 BOLT (M10X1.5X25-MM) | 26 | |
| 8T4137 | 60 BOLT (M10X1.5X20-MM) | 24 | |
| 8T4195 | 61 BOLT (M10X1.5X30-MM) | 5 | |
| 8T4223 | 62 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4224 | 63 WASHER-HARD (8.8X16X2-MM THK) | 10 | |
| 8T4908 | 64 BOLT (M8X1.25X25-MM) | 25 | |
| 8T5447 | 65 RING-RETAINING | 3 | |
| 8T7547 | 66 BOLT (M8X1.25X30-MM) | 4 | |
| 9X8256 | 67 WASHER (6.6X12X2-MM THK) | 6 | |
| 1455664 | 68 SEAL (92-CM) | ||
| 7X7877 | 69 STRIP-EDGE (14-CM) | ||
| 7X7877 | 69A STRIP-EDGE (9-CM) | ||
| 1268472 | 70 SEAL (85-CM) |
