System And Components
511-0765 TANK GP-HYDRAULICS/N E8S1-UP
Group No: 511-0765
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1428937 | 1 CAP AS-FILLER (LOCKABLE) | 1 | |
| 2049815 | 2 ELBOW AS | 2 | |
| 6K6307 | SEAL-O-RING | 1 | |
| 8T0315 | SEAL-O-RING | 1 | |
| 8T1682 | ELBOW | 1 | |
| 2068818 | 3 STRAINER | 1 | |
| 2075997 | 4 BREATHER AS (FAST FILL) | 1 | |
| 2608636 | 5 GAUGE-LIQUID LEVEL (SIGHT GLASS) | 1 | |
| 3633445 | 6 STRAINER AS | 2 | |
| 0304606 | SEAL-O-RING | 1 | |
| 3664695 | 7 PLUG AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 3603679 | PLUG-CONNECTOR (9/16-18-THD) | 1 | |
| 3726949 | 8 GASKET | 1 | |
| 3726996 | 9 COVER AS | 1 | |
| 3761286 | 10 FILTER GP-OIL (HYDRAULIC TANK RETURN) | 1 | |
| 3779629 | 11 VALVE-BALL | 1 | |
| 3866219 | 12 ELBOW AS | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1987655 | CONNECTOR | 1 | |
| 4186597 | 13 SWITCH GP-LIQUID LEVEL | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 5110766 | 14 TANK AS-HYDRAULIC | 1 | |
| 1488335 | 15 CONNECTOR AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V8635 | CONNECTOR | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488345 | 16 CONNECTOR AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8638 | CONNECTOR | 1 | |
| 1488353 | 17 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9001 | ELBOW | 1 | |
| 1488355 | 18 ELBOW AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9005 | ELBOW | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488390 | 19 ELBOW AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8626 | ELBOW | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488408 | 20 PLUG AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 9S4183 | PLUG (1-1/16-12-THD) | 1 | |
| 1536237 | 21 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9004 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1724620 | 22 CONNECTOR AS | 1 | |
| 3D2824 | SEAL-O-RING | 2 | |
| 6Y2349 | CONNECTOR | 1 | |
| 2049379 | 23 ELBOW AS | 1 | |
| 6K6307 | SEAL-O-RING | 1 | |
| 8T0315 | SEAL-O-RING | 1 | |
| 2049378 | ELBOW | 1 | |
| 2M9780 | 24 SEAL-O-RING | 1 | |
| 3D2824 | 25 SEAL-O-RING | 1 | |
| 5C7261 | 26 NUT (M8X1.25-THD) | 14 | |
| 5P4116 | 27 WASHER-HARD (8.8X20.5X2-MM THK) | 14 | |
| 8T4223 | 28 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4956 | 29 BOLT (M12X1.75X35-MM) | 4 |
