System And Components
306-7963 PANEL GP-INSTRUMENTS/N D4D1-UP
Group No: 306-7963
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4W5972 | 1 KNOB | 1 | |
| 7G9730 | 2 LAMP AS (120-VOLT, 3-WATT) | 2 | |
| 6V8367 | 2A LOCKWASHER | 1 | |
| 6V8382 | 2B NUT-HEX (11/16-27-THD) | 1 | |
| 1089656 | 3 STRAP-CABLE | 2 | |
| 1105174 | 4 SWITCH (2-POSITION)(VOLTAGE CONTROL ADJUSTMENT) | 1 | |
| 1435085 | 5 BLOCK-CONTACT | 1 | |
| 1435086 | 6 BLOCK-CONTACT | 1 | |
| 1694481 | 7 HINGE AS | 2 | |
| 1694501 | 8 CLIP | 1 | |
| 2069512 | 9 CONTACT | 2 | |
| 2129862 | 10 SWITCH AS-PUSH BUTTON (DISABLE ALARM) | 1 | |
| 2615503 | COLLAR | 1 | |
| 2675498 | SWITCH-PUSH BUTTON (ALARM) | 1 | |
| 2266446 | 11 SWITCH AS-PUSH BUTTON (OPERATOR) | 1 | |
| 2069509 | BUTTON-STOP | 1 | |
| 2615503 | COLLAR | 1 | |
| 2286935 | 12 BLOCK-CONTACT | 3 | |
| 2657951 | 13 GAUGE (FUEL LEVEL) | 1 | |
| 2665359 | 14 SWITCH-ROTARY (2-POSITION)(WARNING LIGHT) | 2 | |
| 2666421 | 15 LOCK AS | 2 | |
| 2671821 | 16 POTENTIOMETER (VOLTAGE ADJUST) | 1 | |
| 2888608 | 17 FASTENER GP-WIRING HARNESS | 7 | |
| 2985189 | 18 BRACKET-TIE | 2 | |
| 3067962 | 19 PLATE AS | 1 | |
| 3067964 | 20 FILM-IDENTIFICATION (CONTROL PANEL) | 1 | |
| 5593671 | 21 SWITCH GP-ROCKER (ENGINE CONTROL MODULE) | 1 | |
| 3067967 | 22 MOUNT | 1 | |
| 3067968 | 23 PLATE-COVER | 1 | |
| 1H4393 | 24 LOCKWASHER | 3 | |
| 0966166 | 25 WASHER-HARD (4.5X9X1-MM THK) | 4 | |
| 0969278 | 26 SCREW-PAN HEAD | 4 | |
| 2N2372 | 27 LAMP (12-VOLT) | 2 | |
| 5C8312 | 28 NUT (M4X0.7-THD) | 3 |
