System And Components
312-5974 LINES GP-AIRFOR USE WITH C32 HYDRO RIG
Group No: 312-5974
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1270929 | 1 CLAMP-V BAND | 2 | |
| 1296400 | 2 ADAPTER | 1 | |
| 2177088 | 3 HOSE | 8 | |
| 2178946 | 4 ELBOW | 1 | |
| 3048532 | 5 BRACKET AS | 4 | |
| 3113631 | 6 BRACKET AS | 1 | |
| 3113632 | 7 BRACKET AS | 1 | |
| 3117505 | 8 TUBE | 1 | |
| 3117506 | 9 TUBE | 1 | |
| 3122141 | 10 TUBE | 1 | |
| 3122142 | 11 TUBE | 1 | |
| 1257484 | 12 SPACER (11X25X36-MM THK) | 2 | |
| 6V5048 | 13 SEAL-O-RING | 1 | |
| 6V6782 | 14 CLIP (SLOT) | 6 | |
| 6V6783 | 15 CLIP (TAB) | 6 | |
| 7X7729 | 16 WASHER (11X25X3-MM THK) | 16 | |
| 8C3089 | 17 SEAL-O-RING | 2 | |
| 8T4133 | 18 NUT (M10X1.5-THD) | 8 | |
| 8T4172 | 19 BOLT (M10X1.5X80-MM) | 2 | |
| 8T4184 | 20 BOLT (M12X1.75X45-MM) | 2 | |
| 8T4186 | 21 BOLT (M10X1.5X40-MM) | 6 | |
| 8T4223 | 22 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4244 | 23 NUT (M12X1.75-THD) | 2 | |
| 9S8002 | 24 PLUG (7/16-20-THD) | 1 | |
| 9X2201 | 25 CLAMP-HOSE | 24 |
