System And Components
293-2887 FILTER GP-ENGINE OILS/N DSJ1-UP
Group No: 293-2887
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1R1808 | 1 FILTER-ENGINE OIL (ADVANCED EFFICIENCY) | 4 | |
| 2N0178 | 2 PANEL | 1 | |
| 2N0179 | 3 COVER-PANEL | 1 | |
| 2N5848 | 4 BASE AS | 1 | |
| 2P3761 | 5 COVER | 2 | |
| 2P4301 | 6 BASE AS-OIL FILTER | 2 | |
| 2P4304 | STUD-HOLLOW | 1 | |
| 2P4303 | 7 BASE AS-OIL FILTER | 2 | |
| 2W8436 | 8 INDICATOR AS-PRESSURE (ENGINE OIL) | 2 | |
| 3N4622 | 9 HOSE AS | 1 | |
| 4H9756 | 10 LEVER-RELEASE CONTROL | 1 | |
| 4N7082 | 11 SHIELD-OIL FILTER | 4 | |
| 4N8150 | 12 SPRING | 2 | |
| 5L5709 | 13 CONNECTOR-SHIELD | 1 | |
| 6N0824 | 14 GASKET | 1 | |
| 6N1258 | 15 HOUSING | 1 | |
| 6N1259 | 16 POINTER | 1 | |
| 6V8628 | 17 ELBOW | 2 | |
| 7N0912 | 18 VALVE GP-FLUID CONTROL (ENGINE OIL) | 1 | |
| 7N0911 | VALVE AS (ENGINE OIL) | 1 | |
| 3F9190 | PIN | 1 | |
| 7N0914 | 19 DETENT AS | 1 | |
| 7W2731 | 20 RETAINER | 2 | |
| 8L8877 | 21 HOSE AS | 1 | |
| 9M0853 | 22 PLUNGER-VALVE | 2 | |
| 2395571 | 23 SEAL-INTEGRAL | 1 | |
| 2433384 | 24 BRACKET | 1 | |
| 2697680 | 25 CLIP | 1 | |
| 2888580 | 26 CLAMP-FUEL LINE | 1 | |
| 2888581 | 27 CLAMP-FUEL LINE | 1 | |
| 2932875 | 28 COVER | 1 | |
| 2932882 | 29 BONNET | 1 | |
| 2932884 | 30 ELBOW | 1 | |
| 2932886 | 31 FLANGE | 1 | |
| 2932889 | 32 TUBE AS | 1 | |
| 2932890 | 33 TUBE AS | 1 | |
| 2938627 | 34 TUBE AS | 1 | |
| 2938628 | 35 TUBE AS | 1 | |
| 2939385 | 36 BRACKET | 1 | |
| 3076121 | 37 BRACKET | 1 | |
| 5166017 | 38 COVER | 1 | |
| 0307961 | 39 ELBOW | 1 | |
| 0815622 | 40 ADAPTER | 2 | |
| 0L1143 | 41 BOLT (3/8-16X2.5-IN) | 2 | |
| 0L1351 | 42 BOLT (3/8-16X0.875-IN) | 2 | |
| 0S1571 | 43 BOLT (3/8-16X1.75-IN) | 12 | |
| 0S1588 | 44 BOLT (3/8-16X1.25-IN) | 6 | |
| 0S1590 | 45 BOLT (3/8-16X2-IN) | 7 | |
| 0S1594 | 46 BOLT (3/8-16X1-IN) | 1 | |
| 0T0573 | 47 BOLT (3/8-16X2.75-IN) | 2 | |
| 1090078 | 48 SEAL-O-RING | 4 | |
| 1647900 | 49 ADAPTER | 1 | |
| 1665396 | 50 SCREW-WASHER HEAD (1/4-20X0.5-IN) | 1 | |
| 1A2029 | 51 BOLT (3/8-16X1.125-IN) | 1 | |
| 1B8704 | 52 KEY-WOODRUFF | 2 | |
| 1C2251 | 53 BOLT (3/8-16X1.87-IN) | 1 | |
| 1L6561 | 54 PLUG (BUTTON) | 1 | |
| 2348937 | 55 SEAL-INTEGRAL | 1 | |
| 2M1538 | 56 STUD-TAPERLOCK (3/8-16X1.6-IN) | 8 | |
| 2P3760 | 57 GASKET | 2 | |
| 2P4305 | 58 GASKET | 6 | |
| 3J7352 | 59 CONNECTOR | 2 | |
| 3P0656 | 60 SEAL-O-RING | 1 | |
| 4B2041 | 61 NUT (6-32-THD) | 2 | |
| 4B5324 | 62 WASHER (3.9X9.6X1.2-MM THK) | 4 | |
| 4J5477 | 63 SEAL-O-RING | 4 | |
| 4M6425 | 64 BOLT (5/16-18X1-IN) | 3 | |
| 4P8134 | 65 CLIP (LADDER) | 1 | |
| 5B2638 | 66 BOLT (3/8-16X5.25-IN) | 4 | |
| 5M2894 | 67 WASHER-HARD (10.2X18.5X2.5-MM THK) | 55 | |
| 5P4116 | 68 WASHER-HARD (8.8X20.5X2-MM THK) | 6 | |
| 5P7813 | 69 SEAL-O-RING | 2 | |
| 6D2928 | 70 BOLT (1/4-20X1.125-IN) | 3 | |
| 6D3479 | 71 CLIP (LOOP)(LOOP) | 3 | |
| 6V3507 | 72 SEAL-RECTANGULAR | 2 | |
| 6V5048 | 73 SEAL-O-RING | 6 | |
| 6V8185 | 74 NUT (1/4-20-THD) | 3 | |
| 6V8189 | 75 NUT (5/16-18-THD) | 3 | |
| 7F9090 | 76 SCREW-DRIVE (NO 8X3/8-IN) | 8 | |
| 7K1181 | 77 STRAP-CABLE | 2 | |
| 7K9197 | 78 ELBOW | 1 | |
| 8B4884 | 79 ELBOW | 2 | |
| 8C3445 | 80 CAP-DUST | 1 | |
| 8C3446 | 81 VALVE-SAMPLING (ENGINE OIL) | 1 | |
| 8M2772 | 82 CLIP (LOOP) | 1 | |
| 8T4205 | 83 WASHER-HARD (7.2X14.5X2-MM THK) | 6 | |
| 9S8752 | 84 NUT-FULL (3/8-16-THD) | 29 | |
| 9X6259 | 85 SCREW-MACHINE (6-32X0.375-IN) | 2 | |
| 9X6458 | 86 WASHER-HARD (10.2X22.5X3-MM THK) | 10 |
