System And Components
489-6273 CONSOLE GP-OPERATORS/N J6B1-UP
Group No: 489-6273
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1V9385 | 1 COVER-EMBLEM | 1 | |
| 1537369 | 2 KNOB GP-STEERING | 1 | |
| 3602370 | 3 COVER | 1 | |
| 3617666 | 4 PLATE AS | 1 | |
| 3617681 | 5 COVER | 1 | |
| 3621469 | 6 CONTROL AS-STEERING | 1 | |
| 3623012 | 7 WHEEL AS | 1 | |
| 1356125 | 8 KEY-WOODRUFF | 1 | |
| 3445673 | 9 NUT (M6X1-THD) | 8 | |
| 3445674 | 10 NUT (M8X1.25-THD) | 1 | |
| 5P4116 | 11 WASHER-HARD (8.8X20.5X2-MM THK) | 1 | |
| 9K5635 | 12 SCREW-TAPPING (8-18X1-IN) | 3 | |
| 9X2038 | 13 WASHER (7X19X2-MM THK) | 4 | |
| 9X2045 | 14 SCREW-TRUSS HEAD (M6X1X20-MM) | 4 | |
| 9X2046 | 15 SCREW-TRUSS HEAD (M6X1X35-MM) | 4 | |
| 9X8256 | 16 WASHER (6.6X12X2-MM THK) | 8 |
