System And Components
424-4768 WIRING GP-CHASSIS -GRADE CONTROLS/N MG5966-UP; GB6446-UP
Group No: 424-4768
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 2 | |
| 1772215 | 2 STRAP-DUAL CLAMP | 1 | |
| 2468370 | 3 GROMMET | 1 | |
| 3369655 | 4 SENSOR AS-INERTIAL (STABLE BLADE) | 1 | |
| 3860444 | HARNESS AS-SENSOR (GRADE CONTROL) | 1 | |
| 3E3383 | WEDGE-RECEPTACLE LOCK (6-PIN) | 1 | |
| 1124550 | SLEEVE (20-CM) | ||
| 1519275 | KIT-RECEPTACLE (6-PIN) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 6 | |
| 4258969 | 5 SWITCH AS-ROCKER (24-VOLT)(RAISE, LOWER) | 1 | |
| 5170931 | 6 COVER AS | 1 | |
| 4652947 | 7 HARNESS AS-SENSOR | 1 | |
| 1305300 | 8 CLIP | 1 | |
| 3445675 | 10 NUT (M10X1.5-THD) | 1 | |
| 6D4636 | 11 CLIP (LOOP) | 1 | |
| 6P4467 | 12 GROMMET | 1 | |
| 6V0292 | 13 PLUG | 1 | |
| 8T4971 | 14 BOLT (M6X1X30-MM) | 2 | |
| 7X7729 | 15 WASHER (11X25X3-MM THK) | 1 | |
| 8J8197 | 16 CLIP | 2 | |
| 8T4121 | 17 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4137 | 18 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4139 | 19 BOLT (M12X1.75X30-MM) | 2 | |
| 8T4223 | 20 WASHER-HARD (13.5X25.5X3-MM THK) | 5 | |
| 8T4244 | 21 NUT (M12X1.75-THD) | 1 | |
| 8T4910 | 22 BOLT (M12X1.75X60-MM) | 2 | |
| 1984775 | 23 WASHER-HARD (6.6X15X6-MM THK) | 2 | |
| 4615738 | 24 FILM-INSTRUCTION (GRADE, SLOPE) | 1 | |
| 4598384 | 25 FILM-INFORMATION (SLOPE CONTROL) | 1 | |
| 3716464 | 26 FILM-IDENTIFICATION (GRADE CONTROL) | 2 | |
| 6V1249 | 28 GROMMET (22-MM ID) | 1 | |
| 5P7465 | 29 CLIP (TAB) | 1 | |
| 5P7464 | 30 CLIP (SLOT) | 1 | |
| 8T4191 | 31 BOLT (M10X1.5X16-MM) | 3 | |
| 3373953 | 32 GUARD AS | 2 | |
| 2062728 | GUARD-HOSE (14-CM) |
