281-6382 WIRING GP-ENGINES/N C7S417-1164

Group No: 281-6382
Part NumberPart NameQty
3S20931 STRAP-CABLE17
4P59182 CLIP4
9R19683 SPACER (10.6X13.6X7-MM THK)1
16367954 STRAP-CABLE1
17833365 NUT-HEX FLANGE (M8X1.25-THD)9
20416116 STRAP-CABLE (DUAL)2
20613457 STRAP-CABLE9
20624238 SADDLE-MOUNTING1
28935849 PLUG AS-CONNECTOR1
8T8737PLUG-SEAL6
2305010PLUG AS-CONNECTOR (6-PIN)1
290556210 MOUNT (DUAL SWIVEL)1
294859911 HARNESS AS-SENSOR (FUEL RAIL PRESSURE)1
2304013PLUG AS-CONNECTOR (3-PIN)1
2304014RECEPTACLE AS-CONNECTOR (3-PIN)1
297321812 CLIP (LADDER)1
298697813 HARNESS AS-ENGINE (ELECTRONIC CONTROL MODULE)1
1028802KIT-RECEPTACLE (2-PIN)1
1028801KIT-RECEPTACLE (12-PIN)1
6K0806STRAP-CABLE1
7K1181STRAP-CABLE2
1003320PLUG AS-CONNECTOR (2-PIN)1
1112416PLUG AS-CONNECTOR (2-PIN)1
1552270KIT-CONNECTING PLUG (2-PIN)3
2304009PLUG AS-CONNECTOR (12-PIN)1
2304011PLUG AS-CONNECTOR (2-PIN)6
2304012RECEPTACLE AS-CONNECTOR (2-PIN)1
2304013PLUG AS-CONNECTOR (3-PIN)5
2305008PLUG AS-CONNECTOR (4-PIN)1
2305010PLUG AS-CONNECTOR (6-PIN)1
2305011RECEPTACLE AS-CONNECTOR (6-PIN)1
2370227PLUG AS-CONNECTOR (3-PIN)3
2388245PLUG AS-CONNECTOR (2-PIN)2
2397349PLUG AS-CONNECTOR (4-PIN)1
2645732PLUG AS-CONNECTOR (120-PIN)1
298697914 HARNESS AS-SENSOR (CGI, TURBOCHARGER SPEED)1
2305008PLUG AS-CONNECTOR (4-PIN)1
2305011RECEPTACLE AS-CONNECTOR (6-PIN)1
2407874PLUG AS-CONNECTOR (2-PIN)2
2407876PLUG AS-CONNECTOR (2-PIN)1
2606728RECEPTACLE AS-CONNECTOR (12-PIN)1
2610524PLUG AS-CONNECTOR (4-PIN)1
302730515 HARNESS AS-SENSOR (ENGINE OIL PRESSURE)1
2370227PLUG AS-CONNECTOR (3-PIN)1
2370228RECEPTACLE AS-CONNECTOR (3-PIN)1
132578916 CLIP (LADDER)2
4P758117 CLIP (LADDER)2
6V231718 BOLT (M8X1.25X30-MM)1
6V521719 BOLT (M8X1.25X20-MM)1
7K118120 STRAP-CABLE8
9M197421 WASHER-HARD (8.8X16X2-MM THK)2
