System And Components
Assembly
100%

274-1501 WIRING GP-ENGINE ELECTRONICS/N C7S204-UP

Group No: 274-1501
Part NumberPart NameQty
3S20931 STRAP-CABLE10
4P59182 CLIP2
10517973 MOUNT7
20416114 STRAP-CABLE (DUAL)3
20613455 STRAP-CABLE3
20624236 SADDLE-MOUNTING3
22988447 CLIP1
26940068 RECEPTACLE AS-CONNECTOR (2-PIN)1
8T8737PLUG-SEAL2
27587409 HARNESS AS-SENSOR (TURBOCHARGER SPEED)1
2175888PLUG AS-CONNECTOR (3-PIN)1
2304011PLUG AS-CONNECTOR (2-PIN)1
278173910 HARNESS AS-SENSOR (ENGINE)(CGI, TURBOCHARGER SPEED,MAF)1
8T8737PLUG-SEAL2
1552265KIT-CONNECTING PLUG (8-PIN)1
2304011PLUG AS-CONNECTOR (2-PIN)1
2304013PLUG AS-CONNECTOR (3-PIN)1
2305008PLUG AS-CONNECTOR (4-PIN)1
280108911 HARNESS AS-ENGINE (UNIT INJECTOR)1
6N7523WASHER (6.48X11.9X1.57-MM THK)1
1355975GROMMET-WIRING1
1552255KIT-CONNECTING PLUG (12-PIN)1
280114912 HARNESS AS-SENSOR (ELECTRONIC CONTROL MODULE)1
1028801KIT-RECEPTACLE (12-PIN)2
1028802KIT-RECEPTACLE (2-PIN)1
1028805KIT-RECEPTACLE (6-PIN)1
1028806KIT-RECEPTACLE (8-PIN)1
1003320PLUG AS-CONNECTOR (2-PIN)1
1265011SEAL-CONNECTOR1
1006674SEAL-CONNECTOR2
1111567SOCKET-TERMINAL4
1112416PLUG AS-CONNECTOR (2-PIN)1
1265011SEAL-CONNECTOR1
1552270KIT-CONNECTING PLUG (2-PIN)4
1552274KIT-CONNECTING PLUG (6-PIN)1
2116807COVER-CONNECTOR1
2304011PLUG AS-CONNECTOR (2-PIN)11
2304013PLUG AS-CONNECTOR (3-PIN)6
2305008PLUG AS-CONNECTOR (4-PIN)2
2370227PLUG AS-CONNECTOR (3-PIN)1
2645732PLUG AS-CONNECTOR (120-PIN)1
123320213 STRAP-CABLE8
132578914 CLIP (LADDER)4
2Y582915 NUT (M10X1.5-THD)1
4P758116 CLIP (LADDER)7
4P813417 CLIP (LADDER)1
5P797018 NUT (M8X1.25-THD)2
6V231719 BOLT (M8X1.25X30-MM)1
6V521720 BOLT (M8X1.25X20-MM)1
6V583921 WASHER (11X21X2.5-MM THK)1
6V883722 BOLT (M6X1X16-MM)1
7K118123 STRAP-CABLE38
9M197424 WASHER-HARD (8.8X16X2-MM THK)4
9X826725 WASHER (6.6X12X2-MM THK)1
