274-5112 WIRING GP-ENGINE ELECTRONICS/N C7S212-242

Group No: 274-5112
Part NumberPart NameQty
3S20931 STRAP-CABLE10
4P59182 CLIP2
10517973 MOUNT7
20613454 STRAP-CABLE3
20624235 SADDLE-MOUNTING3
22988446 CLIP1
26940067 RECEPTACLE AS-CONNECTOR (2-PIN)1
8T8737PLUG-SEAL2
2304012RECEPTACLE AS-CONNECTOR (2-PIN)1
27416158 HARNESS AS-ENGINE (FUEL INJECTION)1
6N7523WASHER (6.48X11.9X1.57-MM THK)1
1355975GROMMET-WIRING1
1552255KIT-CONNECTING PLUG (12-PIN)1
27587409 HARNESS AS-SENSOR (TURBOCHARGER SPEED)1
2304012RECEPTACLE AS-CONNECTOR (2-PIN)1
2175888PLUG AS-CONNECTOR (3-PIN)1
278173810 HARNESS AS-SENSOR (ELECTRONIC CONTROL MODULE)1
1028802KIT-RECEPTACLE (2-PIN)1
1028805KIT-RECEPTACLE (6-PIN)1
1028806KIT-RECEPTACLE (8-PIN)1
1028801KIT-RECEPTACLE (12-PIN)1
1003320PLUG AS-CONNECTOR (2-PIN)1
1265011SEAL-CONNECTOR1
1006674SEAL-CONNECTOR2
1112416PLUG AS-CONNECTOR (2-PIN)1
1265011SEAL-CONNECTOR1
1231199SEAL-CONNECTOR2
1231200SEAL-CABLE (CABLE)2
1257874TUBE-HEAT SHRINK (5.72-MM DIA)(45-CM)
1257875TUBE-HEAT SHRINK (7.44-MM DIA)(30-CM)
1552270KIT-CONNECTING PLUG (2-PIN)2
2116807COVER-CONNECTOR1
2304011PLUG AS-CONNECTOR (2-PIN)11
2304013PLUG AS-CONNECTOR (3-PIN)6
2305008PLUG AS-CONNECTOR (4-PIN)2
2370227PLUG AS-CONNECTOR (3-PIN)1
2645732PLUG AS-CONNECTOR (120-PIN)1
1552274KIT-CONNECTING PLUG (6-PIN)1
278173911 HARNESS AS-SENSOR (ENGINE)(MAF, CGI, AMBIENT AIR)1
2L8079TERMINAL-RING (14-GA TO 16-GA, 3/8-IN SCREW)1
1552265KIT-CONNECTING PLUG (8-PIN)1
2304011PLUG AS-CONNECTOR (2-PIN)1
2304013PLUG AS-CONNECTOR (3-PIN)1
2305008PLUG AS-CONNECTOR (4-PIN)1
123320212 STRAP-CABLE9
132578913 CLIP (LADDER)3
2Y582914 NUT (M10X1.5-THD)1
4P758115 CLIP (LADDER)6
5P797016 NUT (M8X1.25-THD)1
6V231717 BOLT (M8X1.25X30-MM)1
6V583918 WASHER (11X21X2.5-MM THK)1
6V883719 BOLT (M6X1X16-MM)1
7K118120 STRAP-CABLE31
9M197421 WASHER-HARD (8.8X16X2-MM THK)2
9X826722 WASHER (6.6X12X2-MM THK)1
