System And Components
266-2243 WIRING GP-ELECTRONIC CONTROL -HEUI-BS/N C9S188-227
Group No: 266-2243
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 22 | |
| 4P5918 | 2 CLIP | 1 | |
| 0392280 | 3 SPACER (9X16X36-MM THK) | 2 | |
| 1444613 | 4 ANGLE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 1636795 | 5 STRAP-CABLE | 1 | |
| 1899108 | 6 HARNESS AS-SENSOR (FUEL TEMPERATURE) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 1933973 | 7 STRAP-CABLE | 2 | |
| 2041611 | 8 STRAP-CABLE (DUAL) | 6 | |
| 2061345 | 9 STRAP-CABLE | 5 | |
| 2061346 | 10 STRAP-CABLE | 1 | |
| 2683678 | 11 SPACER (11X16X45-MM THK) | 1 | |
| 2758740 | 12 HARNESS AS-SENSOR (TURBOCHARGER SPEED) | 1 | |
| 2175888 | PLUG AS-CONNECTOR (3-PIN) | 1 | |
| 2304012 | RECEPTACLE AS-CONNECTOR (2-PIN) | 1 | |
| 2788844 | 13 PLUG AS-CONNECTOR | 1 | |
| 8T8737 | PLUG-SEAL | 2 | |
| 2304011 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 2860833 | 14 HARNESS AS-CONTROL (ELECTRONIC CONTROL MODULE) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 1028805 | KIT-RECEPTACLE (6-PIN) | 1 | |
| 1003320 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 1112416 | PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 1342540 | RECEPTACLE AS-CONNECTOR (3-PIN) | 1 | |
| 1740503 | KIT-CONNECTING PLUG (3-PIN) | 1 | |
| 2304009 | PLUG AS-CONNECTOR (12-PIN) | 1 | |
| 2304011 | PLUG AS-CONNECTOR (2-PIN) | 4 | |
| 2304012 | RECEPTACLE AS-CONNECTOR (2-PIN) | 1 | |
| 2304013 | PLUG AS-CONNECTOR (3-PIN) | 3 | |
| 2305008 | PLUG AS-CONNECTOR (4-PIN) | 1 | |
| 2305010 | PLUG AS-CONNECTOR (6-PIN) | 1 | |
| 2305011 | RECEPTACLE AS-CONNECTOR (6-PIN) | 1 | |
| 2312295 | PLUG AS-CONNECTOR (8-PIN) | 1 | |
| 2370227 | PLUG AS-CONNECTOR (3-PIN) | 2 | |
| 2388245 | PLUG AS-CONNECTOR (2-PIN) | 2 | |
| 2397349 | PLUG AS-CONNECTOR (4-PIN) | 1 | |
| 2645732 | PLUG AS-CONNECTOR (120-PIN) | 1 | |
| 2868988 | 15 HARNESS AS-SENSOR (ENGINE)(RIGHT SIDE) | 1 | |
| 2305010 | PLUG AS-CONNECTOR (6-PIN) | 1 | |
| 2305011 | RECEPTACLE AS-CONNECTOR (6-PIN) | 1 | |
| 2407874 | PLUG AS-CONNECTOR (2-PIN) | 5 | |
| 2407878 | PLUG AS-CONNECTOR (3-PIN) | 4 | |
| 2606728 | RECEPTACLE AS-CONNECTOR (12-PIN) | 1 | |
| 2610524 | PLUG AS-CONNECTOR (4-PIN) | 1 | |
| 2893584 | 16 PLUG AS-CONNECTOR | 1 | |
| 8T8737 | PLUG-SEAL | 6 | |
| 2305010 | PLUG AS-CONNECTOR (6-PIN) | 1 | |
| 1325789 | 17 CLIP (LADDER) | 4 | |
| 2048000 | 18 MOUNTING-CABLE TIE | 2 | |
| 2804254 | 19 STUD | 1 | |
| 2Y5829 | 20 NUT (M10X1.5-THD) | 1 | |
| 4P7581 | 21 CLIP (LADDER) | 4 | |
| 4P8134 | 22 CLIP (LADDER) | 3 | |
| 5P7970 | 23 NUT (M8X1.25-THD) | 7 | |
| 6V1820 | 24 BOLT (M10X1.5X30-MM) | 1 | |
| 6V5215 | 25 BOLT (M8X1.25X16-MM) | 3 | |
| 6V5839 | 26 WASHER (11X21X2.5-MM THK) | 5 | |
| 6V6317 | 27 BOLT (M10X1.5X20-MM) | 1 | |
| 6V8225 | 28 NUT (M6X1-THD) | 1 | |
| 7K1181 | 29 STRAP-CABLE | 4 | |
| 9M1974 | 30 WASHER-HARD (8.8X16X2-MM THK) | 10 | |
| 9X8267 | 31 WASHER (6.6X12X2-MM THK) | 1 |
