System And Components
341-8435 CONTROL GP-TRANSMISSION HYDS/N PFW629-UP
Group No: 341-8435
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0336028 | 1 SEAL-O-RING | 1 | |
| 1305300 | 2 CLIP | 1 | |
| 1325789 | 3 CLIP (LADDER) | 7 | |
| 9N7446 | 4 LOCKNUT (4-40-THD) | 4 | |
| 1499129 | 5 CLIP (LOOP) | 1 | |
| 1645567 | 6 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1803178 | 7 VALVE GP-RELIEF (TORQUE CONVERTER INLET) | 1 | |
| 1833409 | 8 PLUG AS | 1 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 0335853 | SEAL-O-RING | 1 | |
| 1974652 | 9 VALVE-RELIEF (CLUTCH BACK PRESSURE) | 1 | |
| 2142485 | 10 SENSOR GP-SPEED (TORQUE CONVERTER OUTPUT)(TORQUE CONVERTER OUTPUT) | 1 | |
| 2345013 | 11 SENSOR GP-TEMPERATURE (TRANSMISSION OIL) | 1 | |
| 2345013 | 11A SENSOR GP-TEMPERATURE (TORQUE CONVERTER OIL) | 1 | |
| 2366222 | 12 SENSOR GP-SPEED (TRANSMISSION OUTPUT) | 2 | |
| 2447772 | 13 VALVE GP-MODULATING | 6 | |
| 2764166 | 14 VALVE AS-FLOW CONTROL (FLOW DIVERTER, LUBRICATION) | 1 | |
| 2859066 | 15 BOLT (M8X1.25X65-MM) | 12 | |
| 3045691 | 16 CONTROL GP-UNPROGRAMMED (TRANSMISSION) | 1 | |
| 3193961 | 17 VALVE GP-RETARDER HYD CONTROL | 1 | |
| 3452299 | 18 HARNESS AS-CONTROL (TRANSMISSION) | 1 | |
| 3452300 | 19 HARNESS AS-TRANSMISSION | 1 | |
| 3452309 | 20 BRACKET AS | 1 | |
| 8R1496 | SPACER (10X20X29-MM THK) | 4 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 4 | |
| 3535126 | 21 PLUG AS | 1 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 3710891 | 22 PLATE-SEPARATOR | 1 | |
| 3710892 | 23 GASKET | 1 | |
| 3830811 | 24 VALVE GP-RELIEF (OIL CONTROL)(TRANSMISSION HYDRAULIC CONTROL) | 1 | |
| 3S2093 | 25 STRAP-CABLE | 14 | |
| 4F4097 | 26 SEAL-O-RING | 1 | |
| 4P7428 | 27 CLIP (LADDER) | 3 | |
| 4P7429 | 28 CLIP (LADDER) | 1 | |
| 1961185 | 29 SENSOR GP-SPEED (ENGINE) | 1 | |
| 4P7581 | 30 CLIP (LADDER) | 3 | |
| 5S1522 | 31 RING-SNAP | 2 | |
| 6D5801 | 32 LOCKNUT (8-32-THD) | 8 | |
| 6D7889 | 33 SEAL-O-RING | 6 | |
| 6I1418 | 34 SPACER (8.2X12.7X28.7-MM THK) | 4 | |
| 6V0852 | 35 CAP-DUST | 7 | |
| 6V2480 | 36 SCREW (4-40X0.5-IN) | 4 | |
| 6V5839 | 37 WASHER (11X21X2.5-MM THK) | 1 | |
| 6V6317 | 38 BOLT (M10X1.5X20-MM) | 1 | |
| 6V8352 | 39 SEAL-O-RING | 2 | |
| 8C6354 | 40 CAP-RECEPTACLE (ET CONNECTOR) | 1 | |
| 7K1181 | 41 STRAP-CABLE | 4 | |
| 7U4892 | 42 SCREW (8-32X0.75-IN) | 8 | |
| 7X2541 | 43 BOLT (M8X1.25X140-MM) | 4 | |
| 8T0292 | 44 BOLT (M8X1.25X90-MM) | 12 | |
| 8T4189 | 45 BOLT (M8X1.25X20-MM) | 4 | |
| 8T4223 | 47 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 8T4224 | 48 WASHER-HARD (8.8X16X2-MM THK) | 38 | |
| 8T6868 | 49 BOLT (M12X1.75X80-MM) | 6 | |
| 8T6912 | 50 BOLT (M8X1.25X50-MM) | 8 | |
| 6V5216 | 51 BOLT (M8X1.25X18-MM) | 4 | |
| 8T9655 | 52 MOUNT-ISOLATION | 8 | |
| 9M8406 | 53 CLIP (LOOP) | 1 | |
| 9N0869 | 54 WASHER-HARD (8.8X25.5X2-MM THK) | 4 | |
| 2385088 | 55 SEAL-O-RING | 1 | |
| 2141048 | 56 SPACER (8.8X16X4-MM THK) | 4 | |
| 1305301 | 57 CLIP | 1 |
