System And Components
341-8428 CONTROL GP-TRANSMISSION HYDS/N PFW1-UP
Group No: 341-8428
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 14 | |
| 6D7889 | 2 SEAL-O-RING | 6 | |
| 6I1418 | 3 SPACER (8.2X12.7X28.7-MM THK) | 4 | |
| 6V0852 | 4 CAP-DUST | 7 | |
| 7K1181 | 5 STRAP-CABLE | 4 | |
| 1645567 | 6 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1803178 | 7 VALVE GP-RELIEF (TORQUE CONVERTER INLET) | 1 | |
| 1974652 | 8 VALVE-RELIEF (CLUTCH BACK PRESSURE) | 1 | |
| 2142485 | 9 SENSOR GP-SPEED (TORQUE CONVERTER OUTPUT)(TORQUE CONVERTER OUTPUT) | 1 | |
| 2345013 | 10 SENSOR GP-TEMPERATURE (TRANSMISSION OIL) | 1 | |
| 2345013 | 10A SENSOR GP-TEMPERATURE (TORQUE CONVERTER OIL) | 1 | |
| 2366222 | 11 SENSOR GP-SPEED (TRANSMISSION OUTPUT) | 2 | |
| 2366222 | 11A SENSOR GP-SPEED (ENGINE) | 1 | |
| 2447772 | 12 VALVE GP-MODULATING | 6 | |
| 2664180 | 14 PLATE-SEPARATOR (TRANSMISSION) | 1 | |
| 2764166 | 15 VALVE AS-FLOW CONTROL (TRANSMISSION LUBRICATION) | 1 | |
| 2859066 | 16 BOLT (M8X1.25X65-MM) | 12 | |
| 3045691 | 17 CONTROL GP-UNPROGRAMMED (TRANSMISSION) | 1 | |
| 3049025 | 18 VALVE GP-RELIEF (TRANSMISSION HYDRAULIC CONTROL) | 1 | |
| 3169962 | 19 SEAL-O-RING | 2 | |
| 3452299 | 20 HARNESS AS-CONTROL (TRANSMISSION) | 1 | |
| 3452300 | 21 HARNESS AS-TRANSMISSION | 1 | |
| 3452309 | 22 BRACKET AS | 1 | |
| 8R1496 | SPACER (10X20X29-MM THK) | 4 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 4 | |
| 1305300 | 23 CLIP | 1 | |
| 1325789 | 24 CLIP (LADDER) | 5 | |
| 1422928 | 25 LOCKNUT (4-40-THD) | 4 | |
| 1833409 | 26 PLUG AS | 1 | |
| 9S8002 | PLUG (7/16-20-THD) | 1 | |
| 0335853 | SEAL-O-RING | 1 | |
| 2771873 | 27 CLIP (LADDER) | 1 | |
| 1499129 | 28 CLIP (LOOP) | 1 | |
| 9M8406 | 29 CLIP (LOOP) | 1 | |
| 4P7428 | 30 CLIP (LADDER) | 2 | |
| 4P7429 | 31 CLIP (LADDER) | 1 | |
| 4P7581 | 32 CLIP (LADDER) | 3 | |
| 5S1522 | 33 RING-SNAP | 2 | |
| 6D5801 | 34 LOCKNUT (8-32-THD) | 8 | |
| 6V2480 | 35 SCREW (4-40X0.5-IN) | 4 | |
| 6V5839 | 36 WASHER (11X21X2.5-MM THK) | 1 | |
| 6V8352 | 37 SEAL-O-RING | 2 | |
| 7U4892 | 38 SCREW (8-32X0.75-IN) | 8 | |
| 8T3647 | 39 BOLT (M8X1.25X80-MM) | 9 | |
| 8T4136 | 40 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4189 | 41 BOLT (M8X1.25X20-MM) | 3 | |
| 8T4200 | 42 BOLT (M8X1.25X16-MM) | 1 | |
| 8T4224 | 43 WASHER-HARD (8.8X16X2-MM THK) | 35 | |
| 8T6912 | 44 BOLT (M8X1.25X50-MM) | 8 | |
| 8T9655 | 45 MOUNT-ISOLATION | 8 | |
| 9N0869 | 46 WASHER-HARD (8.8X25.5X2-MM THK) | 4 | |
| 8C6354 | 47 CAP-RECEPTACLE (ET CONNECTOR) | 1 | |
| 5W8591 | 48 BOLT (M8X1.25X18-MM) | 4 |
