System And Components
298-7791 LINES GP-AIRFOR USE WITH FRONT FACING EXHAUST WHEN USING AN AIR INLET SHUTOFF
Group No: 298-7791
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7W1944 | 1 RETAINER | 2 | |
| 8Y5581 | 2 BOSS | 1 | |
| 1440367 | 3 CLAMP-HOSE | 3 | |
| 2056041 | 4 HOSE | 1 | |
| 3869335 | 5 SHUTOFF GP-AIR | 1 | |
| 3216444 | 6 TUBE AS | 1 | |
| 3381957 | 7 PLATE AS | 1 | |
| 1599540 | NUT-WELD (M8X1.25-THD) | 5 | |
| 3389402 | 8 BRACKET | 1 | |
| 0S1594 | 9 BOLT (3/8-16X1-IN) | 2 | |
| 3E4352 | 10 WASHER-HARD (8.8X20.5X2.5-MM THK) | 2 | |
| 3P0654 | 11 SEAL-O-RING | 1 | |
| 5C7261 | 12 NUT (M8X1.25-THD) | 4 | |
| 5L3244 | 13 CLIP | 1 | |
| 5P5700 | 14 SEAL-O-RING | 2 | |
| 7X0613 | 15 WASHER-HARD (8.8X25.5X5-MM THK) | 2 | |
| 6V5219 | 16 BOLT (M8X1.25X40-MM) | 4 | |
| 8T4121 | 17 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4133 | 18 NUT (M10X1.5-THD) | 1 | |
| 8T4182 | 19 BOLT (M10X1.5X45-MM) | 1 | |
| 8T4224 | 20 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 8T4908 | 21 BOLT (M8X1.25X25-MM) | 2 | |
| 9M1974 | 22 WASHER-HARD (8.8X16X2-MM THK) | 4 |
