System And Components
338-1958 LINES GP-AIRType 2
Group No: 338-1958
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7W1944 | 1 RETAINER | 2 | |
| 1440367 | 2 CLAMP-HOSE | 3 | |
| 2056041 | 3 HOSE | 1 | |
| 3869335 | 4 SHUTOFF GP-AIR | 1 | |
| 3226175 | 5 TUBE AS | 1 | |
| 3381957 | 6 PLATE AS | 1 | |
| 1599540 | NUT-WELD (M8X1.25-THD) | 5 | |
| 3389402 | 7 BRACKET | 1 | |
| 0S1594 | 8 BOLT (3/8-16X1-IN) | 2 | |
| 3P0654 | 9 SEAL-O-RING | 1 | |
| 5C7261 | 10 NUT (M8X1.25-THD) | 4 | |
| 5L3244 | 11 CLIP | 1 | |
| 5M2894 | 12 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 5P5700 | 13 SEAL-O-RING | 2 | |
| 7X0613 | 14 WASHER-HARD (8.8X25.5X5-MM THK) | 2 | |
| 6V5219 | 15 BOLT (M8X1.25X40-MM) | 4 | |
| 8T4121 | 16 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4133 | 17 NUT (M10X1.5-THD) | 1 | |
| 8T4196 | 18 BOLT (M10X1.5X35-MM) | 1 | |
| 8T4224 | 19 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 8T4908 | 20 BOLT (M8X1.25X25-MM) | 2 | |
| 9M1974 | 21 WASHER-HARD (8.8X16X2-MM THK) | 4 |
