System And Components
227-4007 CYLINDER & LINES GP-LIFT -RHS/N B2W1-UP
Group No: 227-4007
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9U9121 | 1 CLAMP | 1 | |
| 9U9122 | 2 CLAMP | 1 | |
| 1282573 | 3 HOSE AS | 1 | |
| 1282574 | 4 HOSE AS | 1 | |
| 1293217 | 5 GUARD AS | 1 | |
| 1536251 | 6 CONNECTOR AS | 1 | |
| 9X8260 | CONNECTOR | 1 | |
| 4K1388 | SEAL-O-RING | 1 | |
| 6V8400 | SEAL-O-RING | 1 | |
| 2270843 | 7 CYLINDER GP-BULLDOZER LIFT | 1 | |
| 2274303 | 8 TUBE AS | 1 | |
| 1488391 | 9 ELBOW AS | 1 | |
| 8T8987 | ELBOW | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 4J0520 | 10 SEAL-O-RING | 3 | |
| 5P1075 | 11 WASHER-HARD (10.2X22.5X3-MM THK) | 12 | |
| 7S8920 | 12 CLIP (SLOT) | 1 | |
| 7S8921 | 13 CLIP (TAB) | 1 | |
| 8C3206 | 14 FLANGE-HALF | 2 | |
| 8S0023 | 15 CLIP (SLOT) | 1 | |
| 8S0024 | 16 CLIP (TAB) | 1 | |
| 8T4133 | 17 NUT (M10X1.5-THD) | 2 | |
| 8T4136 | 18 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4196 | 19 BOLT (M10X1.5X35-MM) | 6 |
