System And Components
338-0944 TORQUE CONVERTER GPS/N RHC1-UP
Group No: 338-0944
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3T4007 | 1 CARRIER-PLANETARY | 1 | |
| 3T4008 | 2 GEAR-PLANETARY (23-TEETH) | 3 | |
| 3T4009 | 3 GEAR-RING (82-TEETH) | 1 | |
| 3T4011 | 4 SHAFT AS-PLANETARY | 3 | |
| 2A3746 | PLUG-CUP | 1 | |
| 3T4013 | 5 RETAINER-CARRIER | 1 | |
| 5M7878 | 6 RING-SNAP | 1 | |
| 5P3930 | 7 BEARING AS-ROLLER | 3 | |
| 8E8300 | 8 DISC-THRUST | 6 | |
| 9M2008 | 9 RING-METAL SEAL | 1 | |
| 2330668 | 10 SHAFT AS | 1 | |
| 5J7386 | PLUG-ORIFICE (1/8-27-THD) | 1 | |
| 3380942 | 11 TORQUE CONVERTER GP | 1 | |
| 2D5658 | 12 BALL BEARING | 1 | |
| 2K5986 | 13 PIN-SPRING | 2 | |
| 3S2708 | 14 PIN-SPRING | 3 | |
| 5J3964 | 15 RING-LOCK | 1 | |
| 5P7679 | 16 RACE-SPECIAL ROLLER BEARING | 1 | |
| 6K3630 | 17 RING | 1 | |
| 6V4583 | 18 RING-RETAINING | 1 |
