System And Components
240-7166 DRUM GP-COMPACTORS/N DTM1-UP
Group No: 240-7166
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5088197 | 1 MOUNT | 6 | |
| 2296688 | 2 PLATE AS | 2 | |
| 2407164 | 3 DRUM AS | 1 | |
| 5C3370 | 3A BOSS | 1 | |
| 2430093 | 3B PLATE AS | 2 | |
| 9X6269 | NUT-WELD (M16X2-THD) | 6 | |
| 2296685 | DRUM | 1 | |
| 2407161 | STUD | 8 | |
| 2430095 | 4 PLATE | 2 | |
| 7X2561 | 5 BOLT (M20X2.5X35-MM) | 12 | |
| 8T4123 | 6 WASHER (22X35X3.5-MM THK) | 12 | |
| 8T7338 | 7 BOLT (M16X2X45-MM) | 12 | |
| 9X8257 | 8 WASHER (17.5X30X3.5-MM THK) | 12 | |
| 2173601 | 9 SHIM (3-MM THK) | 6 |
