System And Components
367-6574 MUFFLER & MOUNTING GPS/N XC31-UP
Group No: 367-6574
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3701066 | 1 MUFFLER GP | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 4 | |
| 3917200 | MUFFLER AS | 1 | |
| 3918374 | STRAP-CLAMP | 2 | |
| 3821872 | 2 PIPE AS-EXHAUST EXTENSION | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 4 | |
| 3821875 | 3 TUBE-EXHAUST | 1 | |
| 3821910 | 4 TUBE AS-EXHAUST | 1 | |
| 3821914 | 5 PLATE | 1 | |
| 3821921 | 6 PLATE AS | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 2 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 3 | |
| 0993649 | 7 BOLT (M8X1.25X40-MM) | 2 | |
| 1984776 | 8 WASHER-HARD (8.8X20X8-MM THK) | 2 | |
| 1984777 | 9 WASHER-HARD (11X25X10-MM THK) | 2 | |
| 3887007 | 10 CLAMP-BENT BOLT | 2 | |
| 5P4116 | 11 WASHER-HARD (8.8X20.5X2-MM THK) | 2 | |
| 7X0289 | 12 BOLT (3/8-16X1.875-IN) | 2 | |
| 7X0613 | 13 WASHER-HARD (8.8X25.5X5-MM THK) | 6 | |
| 8T4189 | 14 BOLT (M8X1.25X20-MM) | 6 | |
| 8T4224 | 15 WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 8T4908 | 16 BOLT (M8X1.25X25-MM) | 6 | |
| 8T7547 | 17 BOLT (M8X1.25X30-MM) | 4 |
