117-9982 CONSOLE GP-INSTRUMENTS/N 5ZN1-UP

Group No: 117-9982
Part NumberPart NameQty
9W14941 KIT-SERVICE METER (24-VOLT)1
4W21412 INDICATOR AS-FUEL LEVEL (24-VOLT)(FUEL)1
9G76413 SWITCH GP-START (ENGINE, KEY)1
7N58764 LAMP (24-VOLT, 0.2-AMPERE)1
2N23715 LAMP AS-INDICATOR (RED)1
2V7088LENS-RED1
6V8367LOCKWASHER1
6V8382NUT-HEX (11/16-27-THD)1
6V8817SCREW-MACHINE (4-36X4.76-IN)2
2V70876 LENS-AMBER1
5D00197 LAMP (24-VOLT)1
10535428 DIODE GP3
8J12569 CLIP1
9X825610 WASHER (6.6X12X2-MM THK)1
3S209311 STRAP-CABLE4
7K118112 STRAP-CABLE7
117083913 HARNESS AS-PANEL1
1S9593STRAP-CABLE15
1552265KIT-CONNECTING PLUG (8-PIN)3
7X6222PLUG AS-CONNECTOR (24-PIN)1
7X8831DIODE1
8T8737PLUG-SEAL17
0868835LIGHTING GP-WARNING1
109103614 BOX AS-INSTRUMENT1
109710815 FILM-INSTRUMENT1
6V950116 LOCKWASHER2
5P850017 KEY2
104621618 PLUG1
9D373719 PLUG-BUTTON2
