System And Components
436-3929 PANEL GP-CONTROL -FUSE, RELAY PANELS/N P541-UP; CS51-UP
Group No: 436-3929
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 8 | |
| 2039007 | 2 NUT (1-1/2-18-THD) | 1 | |
| 3270325 | 3 STRAP-CABLE | 3 | |
| 3407160 | 4 CONVERTER-POWER (24-VOLT TO 12-VOLT) | 1 | |
| 3531691 | 5 PANEL AS-INSTRUMENT | 1 | |
| 3560847 | 6 PLATE | 1 | |
| 3624304 | 7 BRACKET | 4 | |
| 3642968 | 8 FILM-IDENTIFICATION (INSTRUMENT PANEL) | 1 | |
| 3734806 | 9 BRACKET | 1 | |
| 3734807 | 10 INSULATION-SOUND SUPPRESSION | 1 | |
| 4415944 | 11 CONTROLLER | 1 | |
| 4559568 | 12 CAP AS | 1 | |
| 4974955 | 13 HARNESS AS-PANEL | 1 | |
| 0966166 | 14 WASHER-HARD (4.5X9X1-MM THK) | 4 | |
| 1305300 | 15 CLIP | 1 | |
| 1325789 | 16 CLIP (LADDER) | 3 | |
| 1H3244 | 17 LOCKWASHER | 2 | |
| 2110052 | 18 NUT (1-11/16-18-THD) | 1 | |
| 4B4863 | 19 WASHER (4.7X11X1.2-MM THK) | 8 | |
| 5C2890 | 20 NUT (M6X1-THD) | 2 | |
| 5P4116 | 21 WASHER-HARD (8.8X20.5X2-MM THK) | 10 | |
| 5P7162 | 22 SCREW-MACHINE (10-32X0.5-IN) | 8 | |
| 6V9672 | 23 SCREW-MACHINE (M4X0.7X16-MM) | 2 | |
| 7X2535 | 24 BOLT (M6X1X60-MM) | 2 | |
| 8T4138 | 25 BOLT (M6X1X20-MM) | 4 | |
| 8T4189 | 26 BOLT (M8X1.25X20-MM) | 8 | |
| 8T4205 | 27 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 8T4223 | 28 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8T4244 | 29 NUT (M12X1.75-THD) | 1 | |
| 8T4908 | 30 BOLT (M8X1.25X25-MM) | 2 | |
| 9K0700 | 31 GROMMET | 1 | |
| 9X1046 | 32 SCREW (M4X0.7X18-MM) | 2 | |
| 9X8256 | 33 WASHER (6.6X12X2-MM THK) | 6 |
