System And Components
109-3960 PLANETARY GP-FINAL DRIVE -FRONTS/N 5HN1-191
Group No: 109-3960
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1C9427 | 1 SEAL GP-DUO-CONE | 1 | |
| 1108368 | 2 BEARING-CUP | 1 | |
| 1108369 | 3 CONE-BEARING | 1 | |
| 1108371 | 4 STUD | 10 | |
| 1109325 | 5 GEAR-PLANETARY | 3 | |
| 1108364 | 6 RING-RETAINING | 3 | |
| 1C3726 | 7 PIN | 3 | |
| 1C3876 | 8 WASHER-THRUST | 12 | |
| 1108716 | 9 BEARING AS-NEEDLE | 57 | |
| 7X0292 | 10 BOLT (3/8-16X4.5-IN) | 20 | |
| 9X0881 | 11 PLUG | 3 | |
| 1109323 | 12 GEAR-PLANETARY | 3 | |
| 1109322 | 13 CARRIER | 1 | |
| 1109326 | 14 SHAFT-PLANETARY | 3 | |
| 1P6071 | 15 RACE-THRUST BEARING | 1 | |
| 1108363 | 16 WASHER-THRUST (13.59X31.42X3.94-MM THK) | 1 | |
| 1109321 | 17 GEAR-SUN | 1 | |
| 1108365 | 18 BEARING-ROLLER CYLINDER | 3 | |
| 1109324 | 19 GEAR-SUN | 1 | |
| 0773064 | 20 SEAL-O-RING | 1 | |
| 1109316 | 21 GEAR-RING | 1 | |
| 5B5821 | 22 DOWEL | 2 | |
| 1108715 | 23 SEAL-O-RING | 1 | |
| 1108362 | 24 SPACER-THRUST (13.59X31.42X3.94-MM) | 1 | |
| 5J3864 | 25 RING-LOCK | 1 | |
| 1108370 | 26 BEARING-CUP | 1 | |
| 1595846 | 27 PLUG-MAGNETIC | 2 | |
| 1C4388 | PLUG-MAGNETIC | 2 | |
| 1108366 | 28 CONE-BEARING | 1 | |
| 1109320 | 29 BRAKE-INPUT | 1 | |
| 1G8332 | 30 RING-RETAINING | 1 | |
| 1108634 | 31 COUPLING | 1 | |
| 1154461 | 32 NUT-BEARING | 1 | |
| 1622824 | 33 COVER-REAR | 1 | |
| 1177902 | KIT-BRAKE SPRING | 1 | |
| 1109328 | KIT-SEAL | 1 | |
| 1109329 | KIT-BRAKE LINING | 1 |
