System And Components
168-7475 PLANETARY GP-FINAL DRIVE -REARS/N 5HN462-462; 5HN471-712
Group No: 168-7475
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1C9427 | 1 SEAL GP-DUO-CONE | 1 | |
| 1108366 | 2 CONE-BEARING | 1 | |
| 1108370 | 3 BEARING-CUP | 1 | |
| 1108371 | 4 STUD | 10 | |
| 1870962 | 5 GEAR-PLANETARY | 4 | |
| 1108364 | 6 RING-RETAINING | 4 | |
| 1C3726 | 7 PIN | 3 | |
| 1C3828 | 8 WASHER-THRUST | 12 | |
| 1C3784 | 9 ROLLER-NEEDLE | 54 | |
| 7X0294 | 10 BOLT (3/8-16X5-IN) | 20 | |
| 9X0881 | 11 PLUG | 3 | |
| 1109315 | 12 GEAR-PLANETARY | 3 | |
| 1109314 | 13 CARRIER | 1 | |
| 1109318 | 14 SHAFT-PLANETARY | 3 | |
| 1P6071 | 15 RACE-THRUST BEARING | 1 | |
| 1108363 | 16 WASHER-THRUST (13.59X31.42X3.94-MM THK) | 1 | |
| 1109313 | 17 GEAR-SUN | 1 | |
| 1109317 | 18 GEAR-SUN | 1 | |
| 0773064 | 19 SEAL-O-RING | 1 | |
| 1774991 | 20 BEARING-ROLLER | 4 | |
| 1627568 | 21 PIN-DOWEL | 2 | |
| 1109316 | 22 GEAR-RING | 1 | |
| 1108362 | 23 SPACER-THRUST (13.59X31.42X3.94-MM) | 1 | |
| 5J3864 | 24 RING-LOCK | 1 | |
| 1108369 | 25 CONE-BEARING | 1 | |
| 1595846 | 26 PLUG-MAGNETIC | 2 | |
| 1108368 | 27 BEARING-CUP | 1 | |
| 1109320 | 28 BRAKE-INPUT | 1 | |
| 0779990 | 29 RING-RETAINING | 1 | |
| 1108633 | 30 COUPLING | 1 | |
| 1154461 | 31 NUT-BEARING | 1 | |
| 1108715 | 32 SEAL-O-RING | 1 | |
| 1476575 | 33 COVER-REAR | 1 | |
| 1774989 | 34 RING-RETAINING | 8 | |
| 1177902 | KIT-BRAKE SPRING | 1 | |
| 1109328 | KIT-SEAL | 1 | |
| 1109329 | KIT-BRAKE LINING | 1 |
