System And Components
211-0252 PLANETARY GP-FINAL DRIVE -FRONTS/N 5HN830-UP
Group No: 211-0252
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1517516 | 1 PLUG-DRAIN | 1 | |
| 1517517 | 2 SEAL-O-RING | 1 | |
| 2072814 | 3 SEAL-O-RING | 1 | |
| 2072816 | 4 RING-BACKUP | 1 | |
| 9W4098 | 5 SEAL GP-DUO-CONE | 1 | |
| 1910529 | 6 CONE | 2 | |
| 1910530 | 7 CUP | 2 | |
| 1929762 | 8 STUD | 10 | |
| 2072813 | 9 SEAL-O-RING | 1 | |
| 2072815 | 10 RING-BACKUP | 1 | |
| 1770013 | 11 PISTON-BRAKE | 1 | |
| 7U3538 | 12 RING-RETAINING | 1 | |
| 1910070 | 13 GEAR-PLANETARY | 4 | |
| 6V5201 | 14 RING-RETAINING | 4 | |
| 1912293 | 15 SHAFT-PLANETARY | 3 | |
| 9S8007 | 16 PLUG | 2 | |
| 7J0204 | 17 SEAL-O-RING | 2 | |
| 1517502 | 18 WASHER-ANTIROTATION | 3 | |
| 1929770 | 19 GEAR-PLANETARY | 3 | |
| 1517510 | 20 NEEDLE | 108 | |
| 1517500 | 21 WASHER-GEAR | 3 | |
| 1517505 | 22 RING-RETAINING | 3 | |
| 1914441 | 23 KIT-SHIM (INCLUDES 3-SHIMS)(INCLUDES 3 SHIMS) | 1 | |
| 1912287 | 24 PAD | 1 | |
| 1929769 | 25 GEAR-INPUT SHAFT | 1 | |
| 1914440 | 26 RING-RETAINING | 1 | |
| 1929759 | 27 COVER-OUTPUT | 1 | |
| 9S8004 | 28 PLUG (9/16-18-THD) | 3 | |
| 3J1907 | 29 SEAL-O-RING | 3 | |
| 0961331 | 30 BOLT-SOCKET HEAD (M10X1.5X120-MM) | 32 | |
| 1908501 | 31 SEAL-O-RING | 2 | |
| 1912280 | 32 GEAR-RING | 1 | |
| 1929771 | 33 CARRIER-PLANETARY | 1 | |
| 1910066 | 34 GEAR-SUN | 1 | |
| 1517501 | 35 DISC | 1 | |
| 1912284 | 36 NUT-BEARING | 1 | |
| 1677938 | 37 SHIM | 1 | |
| 1929757 | 38 HOUSING-ROTATING | 1 | |
| 1368064 | 39 DISC-FRICTION | 4 | |
| 1368068 | 40 DISC-MIDDLE | 5 | |
| 2189878 | SHIM (0.1-MM THK) | 1 | |
| 2189880 | SHIM (0.2-MM THK) | 1 | |
| 1929760 | 41 HUB | 1 | |
| 1912288 | 42 PLUG-ORIFICE | 1 | |
| 1475582 | 43 BEARING | 1 | |
| 1929768 | 44 COUPLING-INPUT | 1 | |
| 0957952 | 45 RING | 1 | |
| 2Y8422 | 46 SCREW (M6X16-MM) | 1 | |
| 1912281 | 47 WASHER-RETAINING | 1 | |
| 2072817 | 48 SPRING | 16 | |
| 1770014 | 49 DISC-RETAINING | 1 |
