System And Components
133-5079 CONTROL GP-HYDRAULICS/N 5HN139-629
Group No: 133-5079
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1162222 | 1 PLATE AS | 1 | |
| 1241863 | 2 CLAMP | 1 | |
| 1103886 | 3 BOOT | 1 | |
| 1241886 | 4 PLATE | 1 | |
| 1241864 | 5 BRACKET-PIVOT | 1 | |
| 1354384 | 6 BRACKET | 1 | |
| 1241893 | 7 ADJUSTER | 1 | |
| 9S1354 | 8 NUT (5/8-18-THD) | 1 | |
| 1241888 | 9 SLEEVE-BOOT | 1 | |
| 1241883 | 10 WASHER | 4 | |
| 1241884 | 11 SHOE-BRONZE WEAR | 1 | |
| 1354383 | 12 SCREW-PAN HEAD | 6 | |
| 1447861 | 13 CAM | 1 | |
| 1167490 | 14 SWITCH (NEUTRAL START) | 1 | |
| 1355416 | 15 SCREW-PAN HEAD | 2 | |
| 1241878 | 16 SCREW-PAN HEAD | 4 | |
| 1131095 | 17 HOUSING | 2 | |
| 1241860 | 18 HANDLE-PIPE | 1 | |
| 1241873 | 19 SCREW-PAN HEAD | 1 | |
| 1162464 | 20 SPACER | 1 | |
| 1163064 | 21 ANCHOR | 3 | |
| 1243048 | 22 BOLT | 2 | |
| 4F3590 | 23 SCREW AS-MACHINE | 1 | |
| 7S9930 | 24 RING-RETAINING | 2 | |
| 1241861 | 25 PIN-PIVOT | 1 | |
| 9X6258 | 26 SCREW-MACHINE (6-32X0.5-IN) | 1 | |
| 5H6555 | LOCKWASHER | 1 | |
| 8M2771 | 27 CLIP | 1 | |
| 1170690 | 28 HARNESS AS | 1 | |
| 1356145 | 29 GASKET | 1 | |
| 7M2697 | 30 SCREW-SOCKET (5/16-18X1-IN) | 1 | |
| 1243050 | 31 CAPSULE-METERING | 2 | |
| 1243049 | 32 CAPSULE-PLUNGER | 2 | |
| 1241865 | 33 LOCKNUT | 5 | |
| 1447857 | 34 SETSCREW | 1 | |
| 6B4540 | 35 NUT (4-40-THD) | 6 | |
| 1071716 | 36 SCREW (4-1/2-40X0.63-IN) | 4 | |
| 1071719 | 37 SWITCH-PUSH BUTTON (VIBRATORY) | 1 | |
| 1071721 | 38 CAP | 1 | |
| 1071720 | 39 RING-RETAINING | 1 | |
| 1071723 | 40 GASKET | 2 | |
| 1072091 | 41 BOLT (4-40X0.5-IN) | 2 | |
| 3H3680 | 42 NUT-JAM (1/2-13-THD) | 1 | |
| 5L4758 | 43 SEAL-O-RING | 1 | |
| 1390235 | 44 GASKET | 1 | |
| 1167490 | 45 SWITCH (AUTO/VIB FORWARD) | 1 | |
| 1167490 | 46 SWITCH (AUTO/VIB REVERSE) | 1 | |
| 1241881 | 47 BOLT | 1 | |
| 1G5927 | KIT-METERING CAP SEAL | 2 | |
| 1G5928 | KIT-PLUNGER SEAL | 2 |
