System And Components
419-0677 PUMP GP-FUEL INJECTIONS/N W7N1-UP
Group No: 419-0677
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5W1437 | 1 LOCKWASHER | 2 | |
| 1003752 | 2 STUD (M8X1.25X30-MM) | 2 | |
| 1113422 | 3 NUT (M14X1.5-THD) | 1 | |
| 1857149 | 4 BOLT (M8X1.25X35-MM) | 4 | |
| 2774223 | 5 PLUG | 1 | |
| 3287837 | 6 GEAR (36-TEETH) | 1 | |
| 3303036 | 7 GASKET | 1 | |
| 3316841 | 8 BOLT (M8X1.25X30-MM) | 2 | |
| 3472165 | 9 PLATE-ADAPTER | 1 | |
| 3708363 | 10 PUMP AS | 1 | |
| 3373905 | 10A SENSOR-TEMPERATURE (FUEL TEMPERATURE) | 1 | |
| 3582583 | 10B VALVE (12-VOLT) | 1 | |
| 4201641 | 11 LINE AS-FUEL | 1 | |
| 1783336 | 12 NUT-HEX FLANGE (M8X1.25-THD) | 2 | |
| 6I0645 | 13 BOLT (M8X1.25X25-MM) | 2 | |
| 6I4072 | 14 BOLT (M8X1.25X14-MM) | 2 | |
| 1113423 | 15 WASHER | 1 | |
| 6V8676 | 16 SEAL-O-RING | 1 |
