System And Components
341-5886 CYLINDER GP-BRAKE -RHS/N ASN1-UP; ASR1-UP
Group No: 341-5886 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1526144 | 1 PLUG AS-DRAIN (MAGNETIC)(BRAKE) | 1 | |
| 6V6228 | SEAL-O-RING | 1 | |
| 2043068 | 2 PIN | 3 | |
| 2043069 | 3 SCREW | 3 | |
| 2154514 | 4 SEAL-O-RING | 3 | |
| 2234315 | 5 ADAPTER | 3 | |
| 2094272 | 6 PLUG | 3 | |
| 2088978 | 7 PLUG | 1 | |
| 2074255 | 8 PLUG | 1 | |
| 2043087 | 9 RING | 1 | |
| 2043088 | 10 SLEEVE | 1 | |
| 2234313 | 11 WASHER (120X210X6-MM THK) | 2 | |
| 2295096 | 12 SEAL-O-RING | 1 | |
| 3487130 | 13 SPRING-BRAKE | 3 | |
| 3487131 | 14 BUSHING-BRAKE | 3 | |
| 1990681 | 15 WASHER (6.2X16.5X2-MM THK) | 3 | |
| 8T0640 | 16 BOLT (M6X1X30-MM) | 3 | |
| 2093041 | 17 SEAL-O-RING | 1 | |
| 0336039 | 18 SEAL-O-RING | 3 | |
| 2043085 | 19 RING | 3 | |
| 2043089 | 20 PISTON-BRAKE | 1 | |
| 8F6230 | 21 SEAL-O-RING | 1 | |
| 1990670 | 22 SCREW-PURGE | 1 | |
| 3415893 | 23 PISTON-BRAKE | 1 | |
| 3415891 | 24 HOUSING-BRAKE | 1 | |
| 3487132 | 25 PISTON-BRAKE | 3 | |
| 1073117 | 26 SEAL-O-RING | 3 | |
| 2234314 | 27 KIT-ADJUSTER | 1 |
