System And Components
386-5384 AXLE GPPART OF 386-5614 AXLE & MTG GP-DRIVE
Group No: 386-5384
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1979155 | 1 BREATHER (AXLE) | 2 | |
| 3415874 | 2 HOUSING-AXLE | 2 | |
| 2094295 | 3 SEAL-RING | 4 | |
| 2094272 | 4 PLUG | 7 | |
| 2234315 | 5 ADAPTER | 6 | |
| 3274152 | 6 SEAL-O-RING | 6 | |
| 3415891 | 7 HOUSING-BRAKE | 1 | |
| 1526144 | 8 PLUG AS-DRAIN (MAGNETIC) | 5 | |
| 6V6228 | SEAL-O-RING | 1 | |
| 1990670 | 9 SCREW-PURGE | 2 | |
| 2074255 | 10 PLUG | 6 | |
| 3415890 | 11 HOUSING-BRAKE | 1 | |
| 2103100 | 12 BUSHING | 2 | |
| 2103098 | 13 SEAL | 2 | |
| 2235550 | 14 BOLT (M14X2X140-MM) | 22 | |
| 8T5001 | 15 BOLT (M12X1.75X130-MM) | 4 | |
| 8M8997 | 16 SEAL-O-RING | 2 | |
| 2416180 | 17 WASHER (10X14X1-MM THK) | 2 | |
| 4421487 | 18 PLUG | 2 | |
| 2227130 | 19 KIT-BEVEL GEAR | 1 | |
| 2097462 | 19A WASHER (40X50X2-MM THK) | 2 | |
| 2108469 | 19B SHIM (COLLAPSIBLE) | 1 | |
| 2111313 | 19C LOCKWASHER | 1 | |
| 2111314 | 19D NUT-RING (M40X1.5-THD) | 1 | |
| 2094303 | 20 SHIM (2.5-MM THK) | 1 | |
| 2094304 | SHIM (2.6-MM THK) | 1 | |
| 2094305 | SHIM (2.7-MM THK) | 1 | |
| 2094306 | SHIM (2.8-MM THK) | 1 | |
| 2094307 | SHIM (2.9-MM THK) | 1 | |
| 2094308 | SHIM (3-MM THK) | 1 | |
| 2938765 | SHIM (3.1-MM THK) | 1 | |
| 2094309 | SHIM (3.2-MM THK) | 1 | |
| 2094310 | SHIM (3.3-MM THK) | 1 | |
| 2094311 | SHIM (3.4-MM THK) | 1 | |
| 1367808 | 30 BEARING AS-TAPERED ROLLER | 2 | |
| 2097454 | 31 NUT (M94X2-THD) | 2 | |
| 9W0614 | 32 CONE | 2 | |
| 9W0615 | 33 CUP | 2 | |
| 2234312 | 34 KIT-DIFFERENTIAL | 1 | |
| 2087905 | 35 PLATE-END | 2 | |
| 2087907 | 36 PLATE | 10 | |
| 2087906 | 37 PLATE | 8 | |
| 8T4171 | 38 BOLT (M6X1X12-MM) | 2 | |
| 6V5815 | 39 BOLT (M10X1.5X75-MM) | 14 | |
| 2094199 | 40 HOUSING-DIFFERENTIAL | 1 | |
| 2087788 | 41 GEAR-CROWN (77-TEETH) | 2 | |
| 2159546 | 42 CARRIER | 2 | |
| 2087786 | 43 RING-LOCK | 2 | |
| 1990718 | 44 BEARING | 4 | |
| 5H4909 | 45 SEAL-O-RING | 2 | |
| 2949807 | 46 KIT-WHEEL FLANGE | 2 | |
| 1597400 | 46A STUD | 10 | |
| 3112535 | 46B FLANGE-WHEEL | 1 | |
| 1687010 | 47 SEAL-LIP TYPE | 2 | |
| 1658855 | 48 BUSHING | 16 | |
| 1691637 | 49 BOLT (M14X1.5X65-MM) | 16 | |
| 2043093 | 50 PLATE | 4 | |
| 2172895 | 51 DISC-BRAKE | 4 | |
| 2097475 | 52 HUB | 2 | |
| 2043091 | 53 PLATE | 2 | |
| 2043087 | 54 RING | 2 | |
| 2043088 | 55 SLEEVE | 2 | |
| 2234313 | 56 WASHER (120X210X6-MM THK) | 4 | |
| 2093041 | 57 SEAL-O-RING | 2 | |
| 2043089 | 58 PISTON-BRAKE | 2 | |
| 5C5306 | 59 RING-RETAINING | 6 | |
| 2287089 | 60 SEAL-O-RING | 6 | |
| 2100894 | 61 SEAL-O-RING | 2 | |
| 3487132 | 62 PISTON-BRAKE | 6 | |
| 1073117 | 63 SEAL-O-RING | 6 | |
| 3415893 | 64 PISTON-BRAKE | 2 | |
| 3487130 | 65 SPRING-BRAKE | 2 | |
| 3487131 | 66 BUSHING-BRAKE | 2 | |
| 1990681 | 67 WASHER (6.2X16.5X2-MM THK) | 2 | |
| 8T0640 | 68 BOLT (M6X1X30-MM) | 2 | |
| 2234317 | 69 SHAFT | 2 | |
| 9X6378 | 70 RING-RETAINING | 2 | |
| 2103099 | 71 SLEEVE | 2 | |
| 2234310 | 72 SHAFT | 2 | |
| 3886412 | 73 BOLT (M10X1.25X50-MM) | 6 | |
| 3120336 | 74 BLOCK-THRUST | 6 | |
| 3120335 | 75 GEAR-PLANETARY (31-TEETH) | 6 | |
| 3045673 | 76 WASHER-THRUST (40X60X1.5-MM THK) | 6 | |
| 3318522 | 77 BEARING AS-NEEDLE | 6 | |
| 2158060 | 78 SHAFT-SUN GEAR | 6 | |
| 1990669 | 79 PLUG (THRUST) | 2 | |
| 2168120 | 80 HUB | 2 | |
| 8C7505 | 81 SCREW-FLAT HEAD (M8X1.25X20-MM) | 4 | |
| 8T4648 | 82 BOLT (M12X1.75X70-MM) | 2 | |
| 3120341 | 83 COVER-FLANGE | 1 | |
| 7X9372 | 84 SEAL-O-RING | 1 | |
| 4960546 | 85 HOUSING | 1 | |
| 4960545 | 86 HOUSING | 1 | |
| 7X2906 | 87 PIN | 1 | |
| 1990667 | 88 DOWEL | 2 | |
| 0969986 | 89 BOLT (M12X1.75X55-MM) | 8 | |
| 1608742 | 90 BOLT (M10X1.5X55-MM) | 6 | |
| 3274054 | 91 PLUG | 2 | |
| 9X2158 | 92 BOLT-SOCKET HEAD (M10X1.5X90-MM) | 2 | |
| 2496465 | 93 FLANGE-MOUNTING | 1 | |
| 2090033 | 94 SEAL | 1 | |
| 2227132 | 95 FLANGE | 1 | |
| 2089008 | 96 BEARING | 1 | |
| 2227131 | 97 GEAR | 1 | |
| 2089009 | 98 BEARING | 1 | |
| 2094314 | 99 WASHER (35X51X3-MM THK) | 1 | |
| 6V5200 | 100 RING-RETAINING | 1 | |
| 2108354 | 101 SEAL-RING | 1 | |
| 2111480 | 102 CLIP-RETAINING | 1 | |
| 2089011 | 103 BEARING | 1 | |
| 2227135 | 104 GEAR | 1 | |
| 7S3002 | 105 BALL BEARING | 1 | |
| 2234316 | 106 COUPLING | 1 | |
| 2111481 | 107 PLUG | 1 | |
| 8T4195 | 108 BOLT (M10X1.5X30-MM) | 6 | |
| 5429590 | 109 PLUG-COVER | 1 | |
| 5429591 | 110 PLUG-COVER | 1 |
