System And Components
454-0264 COVER GP-CONSOLES/N J761-UP
Group No: 454-0264
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3670760 | 1 COVER | 1 | |
| 3672020 | 2 BRACKET AS | 1 | |
| 3683063 | 3 PLATE | 1 | |
| 3998077 | 4 PLATE | 1 | |
| 4152458 | 5 PLATE | 2 | |
| 4190064 | 6 FILM-IDENTIFICATION (FUSE, RELAY PANEL) | 1 | |
| 4430877 | 7 COVER | 1 | |
| 1548079 | 8 NUT-RETAINER | 13 | |
| 1728591 | 9 NUT-CLIP (M6X1-THD) | 2 | |
| 3143025 | 10 SCREW-THUMB (M6X1X16-MM) | 3 | |
| 3445673 | 11 NUT (M6X1-THD) | 4 | |
| 5P5774 | 12 PLUG | 1 | |
| 7X7729 | 13 WASHER (11X25X3-MM THK) | 4 | |
| 8T6466 | 14 BOLT (M10X1.5X60-MM) | 4 | |
| 8Y1816 | 15 SPACER (12.5X25X25-MM THK) | 4 | |
| 9X1046 | 16 SCREW (M4X0.7X18-MM) | 13 | |
| 9X2044 | 17 SCREW-TRUSS HEAD (M6X1X16-MM) | 2 | |
| 9X8256 | 18 WASHER (6.6X12X2-MM THK) | 4 |
