System And Components
340-0396 LINES GP-CHECK VALVE -STICK CYLINDERS/N P8L1-UP
Group No: 340-0396
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5W9857 | 1 FLANGE-HALF | 2 | |
| 1053478 | 2 BOLT-SOCKET HEAD (M10X1.5X35-MM) | 6 | |
| 1167286 | 3 CLAMP-SINGLE | 1 | |
| 1518865 | 4 ELBOW | 1 | |
| 1856798 | 5 HOSE AS | 1 | |
| 1856799 | 6 HOSE AS | 1 | |
| 1875076 | 7 CLAMP AS | 1 | |
| 2635618 | 8 CLAMP AS (SINGLE) | 6 | |
| 2635133 | GROMMET | 2 | |
| 2636333 | 9 CLAMP GP-HYDRAULIC LINES (TWIN SPIKE) | 3 | |
| 2636335 | GROMMET | 2 | |
| 2636336 | GROMMET | 2 | |
| 2637038 | 10 CLAMP GP-HYDRAULIC LINES (SINGLE) | 6 | |
| 2636337 | GROMMET | 2 | |
| 3292352 | 11 TUBE AS | 1 | |
| 3292353 | 12 TUBE AS | 1 | |
| 3292382 | 13 TUBE AS | 1 | |
| 3292383 | 14 TUBE AS | 1 | |
| 3403050 | 15 CLAMP GP-HYDRAULIC LINES (LOGGING) | 2 | |
| 1949389 | PLATE | 1 | |
| 3403060 | 16 TUBE AS | 1 | |
| 3648088 | 17 VALVE GP-CHECK (PILOT OPERATED)(STICK CYLINDER) | 1 | |
| 4J5267 | SEAL-O-RING | 1 | |
| 3861188 | 18 VALVE GP-SHUTTLE (STICK CYLINDER)(STICK CYLINDER) | 1 | |
| 3E4298 | SEAL-O-RING | 1 | |
| 1616154 | SEAL-O-RING | 1 | |
| 1017398 | 19 BOLT-SOCKET HEAD (M10X1.5X40-MM) | 8 | |
| 1017404 | 20 BOLT-SOCKET HEAD (M10X1.5X30-MM) | 30 | |
| 1488336 | 21 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488341 | 22 CONNECTOR AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8713 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1564282 | 23 REDUCER AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8938 | REDUCER | 1 | |
| 4J5267 | 24 SEAL-O-RING | 2 | |
| 5K9090 | 25 SEAL-O-RING | 5 | |
| 5P7466 | 26 CLIP (SLOT) | 1 | |
| 5P7467 | 27 CLIP (TAB) | 1 | |
| 5P7468 | 28 CLIP (SLOT) | 1 | |
| 5P7469 | 29 CLIP (TAB) | 1 | |
| 5P8112 | 30 GROMMET | 1 | |
| 5P8444 | 31 GROMMET (37-MM ID) | 1 | |
| 6V9746 | 32 SEAL-O-RING | 5 | |
| 7K1181 | 33 STRAP-CABLE | 11 | |
| 7X2533 | 34 BOLT (M6X1X35-MM) | 4 | |
| 7X7729 | 35 WASHER (11X25X3-MM THK) | 2 | |
| 9X6581 | 36 NUT-O-RING SEAL (1-14-THD) | 1 | |
| 1856804 | 37 HOSE AS | 2 | |
| 1856805 | 38 HOSE AS | 2 | |
| 2017473 | 39 HOSE AS | 2 |
