System And Components
190-7420 BLADE GPS/N 2RZ1-UP
Group No: 190-7420
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2J5997 | 1 LOCKNUT (1-1/4-7-THD) | 2 | |
| 3B8489 | 2 FITTING-GREASE (1/8-27 PTF) | 3 | |
| 3E9861 | 3 LOCKNUT (5/8-11-THD) | 24 | |
| 4F3654 | 4 BOLT-PLOW (5/8-11X2-IN) | 24 | |
| 7R7638 | 5 CYLINDER GP-HYDRAULIC | 1 | |
| 7X8086 | 6 SUPPORT AS-BLADE | 4 | |
| 7X8087 | 7 SHIM (1.52-MM THK) | 4 | |
| 7X8092 | 8 TUBE | 2 | |
| 7X8093 | 9 SPACER (60.3X75X9.65-MM THK) | 4 | |
| 7X8115 | 10 WASHER (25.4X76.2X6.35-MM THK) | 4 | |
| 8G4189 | 11 BEARING-SELF-ALIGNING | 2 | |
| 9X6496 | 12 RING-RETAINING | 4 | |
| 0775470 | 13 BUSHING-TERMINAL | 1 | |
| 1463148 | 14 EDGE-CUTTING | 2 | |
| 1463149 | 15 EDGE-CUTTING | 2 | |
| 1873248 | 17 BLADE AS | 1 | |
| 6V7676 | 18 NUT (M24X3-THD) | 2 | |
| 6V7688 | 19 LOCKNUT (M20X2.5-THD) | 10 | |
| 7X0429 | 20 BOLT (1-1/4-7X4.5-IN) | 1 | |
| 7X0436 | 21 BOLT (1-1/4-7X9-IN) | 1 | |
| 7X0533 | 22 WASHER-HARD (34X55X6-MM THK) | 4 | |
| 8C3290 | 23 BOLT (M24X3X150-MM) | 2 | |
| 8C8478 | 24 BOLT (M20X2.5X140-MM) | 10 | |
| 8T4122 | 25 WASHER-HARD (17X32X3.5-MM THK) | 24 | |
| 8T4994 | 26 WASHER-HARD (20X36.5X3.5-MM THK) | 10 |
