System And Components
143-5934 PANEL GP-CONTROLS/N AGH1-UP
Group No: 143-5934
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9X1046 | 1 SCREW (M4X0.7X18-MM) | 6 | |
| 3T2357 | 2 SWITCH GP-PUSH BUTTON (HORN) | 1 | |
| 2H3922 | LOCKWASHER | 1 | |
| 3B4501 | LOCKWASHER | 1 | |
| 5L7200 | SCREW (8-32X0.375-IN) | 1 | |
| 6V8363 | SCREW (10-32X0.312-IN) | 2 | |
| 6V8370 | NUT-HEX (3/4-32-THD) | 1 | |
| 7T9515 | KNOB-HORN | 1 | |
| 8F1434 | LOCKWASHER | 2 | |
| 9X0199 | BOOT-SWITCH | 1 | |
| 6T6329 | 3 BEZEL | 3 | |
| 1107887 | 4 SWITCH AS-START (KEY) | 1 | |
| 7T6799 | NUT-MOUNTING (1-32-THD) | 1 | |
| 1164684 | 5 GAUGE GP-FUEL LEVEL (24-VOLT) | 1 | |
| 3L8187 | LOCKWASHER | 3 | |
| 4B5324 | WASHER (3.9X9.6X1.2-MM THK) | 3 | |
| 6V8368 | NUT (6-32-THD) | 3 | |
| 6V8377 | NUT (8-32-THD) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 1288617 | 6 PLATE AS | 1 | |
| 1297184 | 7 FILM-INSTRUCTION (ENGINE START) | 1 | |
| 1352929 | 8 MODULE GP-WARNING INDICATOR | 1 | |
| 1459296 | 9 PLATE | 1 | |
| 6T6066 | 10 SWITCH AS-ROCKER (START AID) | 1 | |
| 3L8187 | LOCKWASHER | 2 | |
| 6V8374 | SCREW-MACHINE (6-32X0.25-IN) | 2 | |
| 9X9099 | 11 SWITCH AS-ROCKER (SPEED SELECT) | 1 | |
| 9X9099 | 12 SWITCH AS-ROCKER (THROTTLE) | 1 | |
| 3L8187 | LOCKWASHER | 6 | |
| 6V8374 | SCREW-MACHINE (6-32X0.25-IN) | 6 | |
| 9X2042 | 13 SCREW-TRUSS HEAD (M6X1X12-MM) | 1 | |
| 6V8927 | 14 BOLT-SOCKET HEAD (6-32X0.5-IN) | 6 | |
| 8T4205 | 15 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 5C2890 | 16 NUT (M6X1-THD) | 3 | |
| 1498097 | 17 HARNESS AS-PANEL | 1 | |
| 2N2371 | 18 LAMP AS-INDICATOR (RED) | 1 | |
| 4P8134 | 19 CLIP (LADDER) | 2 | |
| 2V7087 | 20 LENS-AMBER | 1 | |
| 7K1181 | 21 STRAP-CABLE | 6 | |
| 1533607 | 22 HOUSING AS-GAUGE | 1 | |
| 8D1470 | 23 GROMMET | 1 | |
| 1498101 | 24 BOX-SWITCH | 1 | |
| 1622777 | FILM-INSTRUCTION | 1 | |
| 6V4298 | 25 BOLT (M5X0.8X16-MM) | 4 | |
| 8T0328 | 26 WASHER-HARD (5.5X10X1-MM THK) | 8 | |
| 6V9188 | 27 LOCKNUT (M5X0.8-THD) | 4 | |
| 7N5876 | 28 LAMP (24-VOLT, 0.2-AMPERE) | 1 | |
| 7T0969 | 29 HORN AS (24-VOLT, LOW TONE) | 1 | |
| 8C7581 | SCREW-MACHINE (M4X0.7X8-MM) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 0966166 | WASHER-HARD (4.5X9X1-MM THK) | 2 | |
| 4M7146 | 30 STRAP AS-GROUND | 1 | |
| 8T4136 | 31 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4121 | 32 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4133 | 33 NUT (M10X1.5-THD) | 1 | |
| 5M3062 | 34 BOLT (3/8-16X0.75-IN) | 1 | |
| 8T4896 | 35 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 1046216 | 36 PLUG | 1 | |
| 8T4223 | 37 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 6V8188 | 38 NUT (1/2-13-THD) | 1 | |
| 1053542 | 39 DIODE GP | 3 | |
| 1211241 | 40 KIT-SERVICE METER | 1 | |
| 1142505 | FILM-IDENTIFICATION (SERVICE METER) | 1 | |
| 5D0019 | 41 LAMP (24-VOLT) | 1 | |
| 5P4115 | 42 WASHER-HARD (7.2X19X2-MM THK) | 1 | |
| 6P0699 | 43 GROMMET | 1 | |
| 9X2045 | 44 SCREW-TRUSS HEAD (M6X1X20-MM) | 3 |
