System And Components
153-7110 PANEL GP-INSTRUMENTS/N CFK225-UP; CFP257-UP
Group No: 153-7110
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6V2689 | 1 TUBE-HEAT SHRINK (6.35-MM DIA) | ||
| 2N2371 | 2 LAMP AS-INDICATOR (RED)(ALTERNATOR) | 1 | |
| 6V8367 | LOCKWASHER | 1 | |
| 6V8382 | NUT-HEX (11/16-27-THD) | 1 | |
| 6V8817 | SCREW-MACHINE (4-36X4.76-IN) | 2 | |
| 2V7087 | 3 LENS-AMBER (ALTERNATOR) | 1 | |
| 3S2093 | 4 STRAP-CABLE | 1 | |
| 4M7146 | 5 STRAP AS-GROUND | 1 | |
| 5D0019 | 6 LAMP (24-VOLT)(FUEL LEVEL GAUGE) | 1 | |
| 5P8500 | 7 KEY | 2 | |
| 6T6329 | 8 BEZEL | 3 | |
| 6V8927 | 9 BOLT-SOCKET HEAD (6-32X0.5-IN) | 6 | |
| 7N5876 | 10 LAMP (24-VOLT, 0.2-AMPERE) | 1 | |
| 1046216 | 11 PLUG | 1 | |
| 1053542 | 12 DIODE GP | 3 | |
| 1107887 | 13 SWITCH AS-START (KEY) | 1 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 4 | |
| 7T6799 | NUT-MOUNTING (1-32-THD) | 1 | |
| 1028804 | KIT-RECEPTACLE (4-PIN) | 1 | |
| 1164684 | 14 GAUGE GP-FUEL LEVEL (24-VOLT) | 1 | |
| 3L8187 | LOCKWASHER | 3 | |
| 4B5324 | WASHER (3.9X9.6X1.2-MM THK) | 3 | |
| 6V3507 | SEAL-RECTANGULAR | 1 | |
| 6V8368 | NUT (6-32-THD) | 3 | |
| 6V8377 | NUT (8-32-THD) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 1288617 | 15 PLATE AS | 1 | |
| 1297184 | 16 FILM-INSTRUCTION (ENGINE START) | 1 | |
| 1352929 | 17 MODULE GP-WARNING INDICATOR (ENGINE TEMPERATURE) | 1 | |
| 1459296 | 18 PLATE | 1 | |
| 1211241 | 19 KIT-SERVICE METER | 1 | |
| 1631201 | 20 HORN AS (24-VOLT, LOW TONE) | 1 | |
| 1808576 | 21 PLATE-IDENTIFICATION (ENGINE)(ENGINE) | 1 | |
| 1938566 | 22 HARNESS AS-PANEL (FRONT CONSOLE) | 1 | |
| 1954973 | 23 BRACKET | 1 | |
| 2292313 | 24 HOUSING AS | 1 | |
| 2305455 | 25 PLATE | 1 | |
| 2308093 | 26 FILM-IDENTIFICATION (INSTRUMENT PANEL) | 1 | |
| 4P8134 | 27 CLIP (LADDER) | 2 | |
| 5C2890 | 28 NUT (M6X1-THD) | 3 | |
| 5C7261 | 29 NUT (M8X1.25-THD) | 1 | |
| 5M3062 | 30 BOLT (3/8-16X0.75-IN) | 1 | |
| 5P4115 | 31 WASHER-HARD (7.2X19X2-MM THK) | 1 | |
| 5P4116 | 32 WASHER-HARD (8.8X20.5X2-MM THK) | 1 | |
| 6P0699 | 33 GROMMET | 1 | |
| 6T6066 | 34 SWITCH AS-ROCKER (AIR INLET HEATER) | 1 | |
| 3L8187 | LOCKWASHER | 2 | |
| 6V8374 | SCREW-MACHINE (6-32X0.25-IN) | 2 | |
| 6V8188 | 35 NUT (1/2-13-THD) | 1 | |
| 7K1181 | 36 STRAP-CABLE | 10 | |
| 8D1470 | 37 GROMMET | 1 | |
| 8T4121 | 38 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4133 | 39 NUT (M10X1.5-THD) | 1 | |
| 8T4137 | 40 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4205 | 41 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 8T4223 | 42 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8T4896 | 43 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 9X1046 | 44 SCREW (M4X0.7X18-MM) | 10 | |
| 9X2042 | 45 SCREW-TRUSS HEAD (M6X1X12-MM) | 1 | |
| 9X2045 | 46 SCREW-TRUSS HEAD (M6X1X20-MM) | 3 | |
| 9X9099 | 47 SWITCH AS-ROCKER (THROTTLE) | 1 | |
| 3L8187 | LOCKWASHER | 6 | |
| 6V8374 | SCREW-MACHINE (6-32X0.25-IN) | 6 | |
| 9X9099 | 48 SWITCH AS-ROCKER (SPEED SELECT) | 1 | |
| 3L8187 | LOCKWASHER | 6 | |
| 6V8374 | SCREW-MACHINE (6-32X0.25-IN) | 6 |
