System And Components
153-7110 PANEL GP-INSTRUMENTS/N ASH1-UP
Group No: 153-7110
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2N2371 | 1 LAMP AS-INDICATOR (RED) | 1 | |
| 6V8367 | LOCKWASHER | 1 | |
| 6V8382 | NUT-HEX (11/16-27-THD) | 1 | |
| 6V8817 | SCREW-MACHINE (4-36X4.76-IN) | 2 | |
| 2V7087 | 2 LENS-AMBER | 1 | |
| 4M7146 | 3 STRAP AS-GROUND | 1 | |
| 5D0019 | 4 LAMP (24-VOLT) | 1 | |
| 6T6329 | 5 BEZEL | 3 | |
| 6V8927 | 6 BOLT-SOCKET HEAD (6-32X0.5-IN) | 6 | |
| 6V9188 | 7 LOCKNUT (M5X0.8-THD) | 4 | |
| 1046216 | 8 PLUG | 1 | |
| 1053542 | 9 DIODE GP | 3 | |
| 7X8831 | DIODE | 2 | |
| 1028806 | KIT-RECEPTACLE (8-PIN) | 1 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 4 | |
| 9G3695 | PLUG-SEAL | 4 | |
| 1107887 | 10 SWITCH AS-START (KEY) | 1 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 4 | |
| 7T6799 | NUT-MOUNTING (1-32-THD) | 1 | |
| 1028804 | KIT-RECEPTACLE (4-PIN) | 1 | |
| 1164684 | 11 GAUGE GP-FUEL LEVEL (24-VOLT) | 1 | |
| 3L8187 | LOCKWASHER | 3 | |
| 4B5324 | WASHER (3.9X9.6X1.2-MM THK) | 3 | |
| 6V3507 | SEAL-RECTANGULAR | 1 | |
| 6V8368 | NUT (6-32-THD) | 3 | |
| 6V8377 | NUT (8-32-THD) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 1288617 | 12 PLATE AS | 1 | |
| 1297184 | 13 FILM-INSTRUCTION (ENGINE START) | 1 | |
| 1352929 | 14 MODULE GP-WARNING INDICATOR | 1 | |
| 1459296 | 15 PLATE | 1 | |
| 1498101 | 16 BOX-SWITCH | 1 | |
| 1533607 | 17 HOUSING AS-GAUGE | 1 | |
| 1211241 | 18 KIT-SERVICE METER | 1 | |
| 9X9099 | 19 SWITCH AS-ROCKER (SPEED SELECT) | 1 | |
| 9X9099 | 20 SWITCH AS-ROCKER (VIB ON/OFF) | 1 | |
| 3L8187 | LOCKWASHER | 6 | |
| 6V8374 | SCREW-MACHINE (6-32X0.25-IN) | 6 | |
| 1934127 | 21 FILM (THROTTLE CONTROL) | 1 | |
| 1938566 | 22 HARNESS AS-PANEL (FRONT CONSOLE) | 1 | |
| 1028806 | KIT-RECEPTACLE (8-PIN) | 2 | |
| 1028801 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 8T8737 | PLUG-SEAL | 14 | |
| 9G7069 | SOCKET AS-LAMP | 1 | |
| 1552271 | KIT-CONNECTING PLUG (4-PIN) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 1552265 | KIT-CONNECTING PLUG (8-PIN) | 3 | |
| 1954973 | 23 BRACKET | 1 | |
| 4P8134 | 24 CLIP (LADDER) | 2 | |
| 5C2890 | 25 NUT (M6X1-THD) | 3 | |
| 5C7261 | 26 NUT (M8X1.25-THD) | 1 | |
| 5M3062 | 27 BOLT (3/8-16X0.75-IN) | 1 | |
| 5P4115 | 28 WASHER-HARD (7.2X19X2-MM THK) | 1 | |
| 5P4116 | 29 WASHER-HARD (8.8X20.5X2-MM THK) | 1 | |
| 6P0699 | 30 GROMMET | 1 | |
| 6T6066 | 31 SWITCH AS-ROCKER (AIR INLET HEATER) | 1 | |
| 3L8187 | LOCKWASHER | 2 | |
| 6V8374 | SCREW-MACHINE (6-32X0.25-IN) | 2 | |
| 6V4298 | 32 BOLT (M5X0.8X16-MM) | 4 | |
| 6V8188 | 33 NUT (1/2-13-THD) | 1 | |
| 7K1181 | 34 STRAP-CABLE | 10 | |
| 8D1470 | 35 GROMMET | 1 | |
| 8T0328 | 36 WASHER-HARD (5.5X10X1-MM THK) | 8 | |
| 8T4121 | 37 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4133 | 38 NUT (M10X1.5-THD) | 1 | |
| 8T4137 | 39 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4205 | 40 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 8T4223 | 41 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8T4896 | 42 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 9X1046 | 43 SCREW (M4X0.7X18-MM) | 6 | |
| 9X2042 | 44 SCREW-TRUSS HEAD (M6X1X12-MM) | 1 | |
| 9X2045 | 45 SCREW-TRUSS HEAD (M6X1X20-MM) | 3 | |
| 1631201 | 46 HORN AS (24-VOLT, LOW TONE) | 1 | |
| 7N5876 | 47 LAMP (24-VOLT, 0.2-AMPERE) | 1 |
