System And Components
183-6375 AXLE GP -WITH BRAKESS/N DCL1-UP
Group No: 183-6375
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2234310 | 1 SHAFT | 2 | |
| 1979155 | 2 BREATHER (AXLE) | 1 | |
| 1979155 | 2A BREATHER (GEAR BOX) | 1 | |
| 2097475 | 3 HUB | 2 | |
| 2043093 | 4 PLATE | 4 | |
| 2234311 | 5 PLATE | 4 | |
| 2043091 | 6 PLATE | 2 | |
| 2043086 | 7 PIN | 6 | |
| 2154513 | 8 SEAL-PIN | 6 | |
| 2087907 | 9 PLATE | 10 | |
| 2100934 | 10 SEAL | 6 | |
| 2043085 | 11 RING | 6 | |
| 2110093 | 12 SHAFT | 2 | |
| 2087906 | 13 PLATE | 8 | |
| 2110095 | 14 HOUSING AS | 1 | |
| 2087823 | 15 GEAR-SUN (31-TEETH) | 6 | |
| 2043087 | 16 RING | 2 | |
| 2043088 | 17 SLEEVE | 2 | |
| 2087905 | 18 PLATE-END | 2 | |
| 2080320 | 19 BOLT (M10X1.5X75-MM) | 12 | |
| 2093041 | 20 SEAL-O-RING | 2 | |
| 2043089 | 21 PISTON-BRAKE | 2 | |
| 2097454 | 22 NUT (M94X2-THD) | 2 | |
| 2W9513 | 23 BOLT (M6X1X10-MM) | 2 | |
| 2043073 | 24 PLATE-LOCK | 2 | |
| 2235550 | 25 BOLT (M14X2X140-MM) | 22 | |
| 1526144 | 26 PLUG AS-DRAIN (MAGNETIC) | 7 | |
| 6V6228 | 27 SEAL-O-RING | 7 | |
| 9W0614 | 28 CONE | 2 | |
| 9W0615 | 29 CUP | 2 | |
| 2094267 | 30 PLUG | 5 | |
| 2110092 | 31 WASHER-THRUST (22X42X2-MM THK)(DIFFERENTIAL SIDE GEAR) | 4 | |
| 8F6230 | 32 SEAL-O-RING | 4 | |
| 8M8997 | 33 SEAL-O-RING | 2 | |
| 2094303 | 34 SHIM (2.5-MM THK) | 1 | |
| 2094304 | SHIM (2.6-MM THK) | 1 | |
| 2094305 | SHIM (2.7-MM THK) | 1 | |
| 2094306 | SHIM (2.8-MM THK) | 1 | |
| 2094307 | SHIM (2.9-MM THK) | 1 | |
| 2094308 | SHIM (3-MM THK) | 1 | |
| 2094309 | SHIM (3.2-MM THK) | 1 | |
| 2094310 | SHIM (3.3-MM THK) | 1 | |
| 2094311 | SHIM (3.4-MM THK) | 1 | |
| 2087791 | 35 WASHER-THRUST (11X60X3-MM THK) | 6 | |
| 2158056 | 36 WASHER-THRUST (11X60X3-MM THK) | 6 | |
| 2168120 | 37 HUB | 2 | |
| 1597400 | 38 STUD | 20 | |
| 2103098 | 39 SEAL | 2 | |
| 2103100 | 40 BUSHING | 2 | |
| 2103097 | 41 CLIP | 2 | |
| 2103099 | 42 SLEEVE | 2 | |
| 2110057 | 43 WASHER (40X50X2-MM THK) | 2 | |
| 2111313 | 44 LOCKWASHER | 1 | |
| 2111314 | 45 NUT-RING (M40X1.5-THD) | 1 | |
| 1367808 | 46 BEARING AS-TAPERED ROLLER | 2 | |
| 2108469 | 47 SHIM (COLLAPSIBLE) | 1 | |
| 2234313 | 48 WASHER (120X210X6-MM THK) | 4 | |
| 2100894 | 49 SEAL-O-RING | 2 | |
| 2234314 | 50 KIT-ADJUSTER (AXLE) | 2 | |
| 1122635 | 51 BOLT-SOCKET HEAD (M12X1.75X130-MM) | 4 | |
| 2088978 | 52 PLUG | 2 | |
| 2043068 | 53 PIN | 6 | |
| 2043069 | 54 SCREW | 6 | |
| 2154514 | 55 SEAL-O-RING | 6 | |
| 2234315 | 56 ADAPTER | 6 | |
| 2094272 | 57 PLUG | 6 | |
| 1990670 | 58 SCREW-PURGE | 2 | |
| 2111478 | 59 PIN | 1 | |
| 6V5200 | 60 RING-RETAINING | 1 | |
| 2094314 | 61 WASHER (35X51X3-MM THK) | 1 | |
| 8H5352 | 62 BALL BEARING | 1 | |
| 2227131 | 63 GEAR | 1 | |
| 2059163 | 64 WASHER (16X22X3-MM THK) | 1 | |
| 2229824 | 65 PLUG | 1 | |
| 5P5397 | 66 SEAL-O-RING | 1 | |
| 2227132 | 67 FLANGE | 1 | |
| 1975194 | 68 BALL BEARING | 1 | |
| 3K2518 | 69 BALL BEARING | 1 | |
| 2234316 | 70 COUPLING | 1 | |
| 2111481 | 71 PLUG | 1 | |
| 2227134 | 72 PLUG | 1 | |
| 7T8419 | 73 BALL BEARING | 1 | |
| 1608748 | 74 BOLT (M12X1.75X55-MM) | 8 | |
| 2227135 | 75 GEAR | 1 | |
| 0950929 | 76 RING-RETAINING | 1 | |
| 2108354 | 77 SEAL-RING | 1 | |
| 2151402 | 78 NEEDLE-ROLLER | 6 | |
| 9X6032 | 79 BOLT-SOCKET HEAD (M10X1.5X30-MM) | 6 | |
| 1053479 | 80 BOLT-SOCKET HEAD (M10X1.5X90-MM) | 2 | |
| 8T0341 | 81 BOLT-SOCKET HEAD (M10X1.5X60-MM) | 8 | |
| 2111486 | 82 PIN | 3 | |
| 1788608 | 83 CONE-TAPERED | 4 | |
| 1570739 | 84 SEAL-LIP TYPE | 2 | |
| 2S0480 | 85 CUP-TAPERED ROLLER | 4 | |
| 1990639 | 86 SCREW-FLAT HEAD (M8X1.25X20-MM) | 4 | |
| 5H4909 | 87 SEAL-O-RING | 2 | |
| 2087786 | 88 RING-LOCK | 2 | |
| 1658855 | 89 BUSHING | 16 | |
| 2111974 | 90 BOLT (M14X1.5X65-MM) | 16 | |
| 2087788 | 91 GEAR-CROWN (77-TEETH) | 2 | |
| 2234317 | 92 SHAFT | 2 | |
| 1990669 | 93 PLUG (THRUST) | 2 | |
| 9W7639 | 94 SPACER (40.5X60X2-MM THK) | 6 | |
| 2112238 | 95 BEARING-NEEDLE | 168 | |
| 2158060 | 96 SHAFT-SUN GEAR | 6 | |
| 2112350 | 97 BOLT (M10X1.25X50-MM) | 6 | |
| 2496465 | 98 FLANGE-MOUNTING | 1 | |
| 2234312 | KIT-DIFFERENTIAL (AXLE) | 1 | |
| 2227130 | KIT-BEVEL GEAR (AXLE) | 1 |
