484-2793 LINES GP-AIR CONDITIONERS/N CP71-UP; B7M1-UP

Group No: 484-2793

Part Number	Part Name	Qty
3553148	1 SWITCH AS-PRESSURE (HIGH, LOW)(AIR CONDITIONER COMPRESSOR)	1
1028802	KIT-RECEPTACLE (2-PIN)	1
8T8729	PIN-CONNECTOR (16-GA TO 20-GA)	2
5P3928	2 COUPLING AS-REFRIGERANT (SELF-SEALING)	1
5P3929	3 COUPLING AS-REFRIGERANT (SELF-SEALING)	1
5P3948	4 COUPLING AS-REFRIGERANT (SELF-SEALING)	1
7K1181	5 STRAP-CABLE	1
7K3176	6 COUPLING AS-REFRIGERANT (SELF-SEALING)	1
1028703	7 PLATE-COVER	1
1106393	8 PLATE-INSTRUCTION (AIR CONDITIONER)	1
1772215	9 STRAP-DUAL CLAMP	4
1783620	10 STRAP-DUAL CLAMP	5
1866190	11 ACCUMULATOR GP-REFRIGERANT (CHARGED)	1
3118367	12 PLATE	1
3270282	13 SEAL-INTEGRAL (1/2-IN)	1
3270283	14 SEAL-INTEGRAL (3/4-IN)	1
3626754	15 BRACKET AS	1
3629617	16 HOSE AS	1
3630311	17 HOSE AS	1
3630320	18 HOSE AS	1
3630389	19 HOSE AS	1
3816651	20 HOSE AS	1
3821359	21 HOSE AS	1
1783336	22 NUT-HEX FLANGE (M8X1.25-THD)	2
2320231	23 CLAMP-HALF	2
2458842	24 CLIP (LOOP)	1
2H3924	25 LOCKWASHER	1
3S8664	26 CLIP	1
5P4106	27 NUT (1-7/16-16-THD)	1
5P4107	28 LOCKWASHER	1
5P4116	29 WASHER-HARD (8.8X20.5X2-MM THK)	8
6V1889	30 CLIP (LOOP)	1
6V4356	31 CLIP (SLOT)	1
6V4357	32 CLIP (TAB)	1
7K3304	33 NUT-JAM (1-20-THD)	1
7X2536	34 BOLT (M8X1.25X14-MM)	1
7X7729	35 WASHER (11X25X3-MM THK)	1
8T4196	36 BOLT (M10X1.5X35-MM)	1
8T6870	37 BOLT (M8X1.25X70-MM)	1
8T6912	38 BOLT (M8X1.25X50-MM)	1
8T7547	39 BOLT (M8X1.25X30-MM)	2
9X7378	40 SEAL-O-RING	1
9X7380	41 SEAL-O-RING	1
9X7381	42 SEAL-O-RING	2
9X7382	43 SEAL-O-RING	1
9X7383	44 SEAL-O-RING	4
9X7384	45 SEAL-O-RING	2
